8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller
8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller
8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller
8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller
Specifications
Brand Name :
SZGH
Model Number :
SZGH-CNC2000MDb-4
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
TT in advance / Western Union / Paypal /LC/Alipay/Creditcard
Supply Ability :
300 sets per month
Delivery Time :
within 3-5 days upon receipt of full payment
Packaging Details :
as standard package of SZGH
Application :
Milling Machine or Lathe Machine, or together
Dimension(L*W*H) :
485*310*375mm
Weight :
10KG
Axis :
5 axis
speed :
the max speed is 300m/min
panel :
touch screen main and sub panel
power :
high anti-jamming switch power
copy interface :
USB movable U disc copy interface
Description

8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller

1. Description

SZGH-CNC2000MDb-5 is High-performance type double channel 2-8 Axis CNC controller for milling machine, lathe & turning center ,with 8.4 inches, it can use to auto tool change and tool magazine, and support the binary encoder tool, also with absolutely type application , very higher precision and speed.

it can work on two pcs of lathe machine, or milling machine at same time.

2. Feature:

1) 2-8 Axis double channels series CNC milling and lathe controller

2) able to use to two pcs lathe machine, or milling machine at same time. such as:

A channel working 2 axis lathe,

B channel working with 3 axis milling machine

3) Binary code turret,Support stardard 8 tools, code turret able to 99 pcs tools
4) Support PLC and macro function, and automatic tool exchange function
5) The max speed is 300m/min, feeding speed is 150m/min
6) Adapted servo spindle can realize spindle continous position,rigid tapping,rigid screw processing
7) one channel can work with 5 axis lathe or milling, another channel can work with 3 axis milling or lathe
8) 64MB Memory , 32Mb user store room
9) With USB interface,it supports file operation in flash disk,system configuration and software upgrade
10) Analog voltage output of 0~10V in two channels,support double spindles
11) 32 bits high performance, low power consumption industrial grade ARM microprocessor.
12) 56X32 , user can be edited freely I/O 24X24
13) cutter offset : C
14) English menu, program and interface, full screen edition

Application : CNC lathe machinery , CNC turning machinery , CNC milling machine ,CNC milling and lathe

together equipment

8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller8.4 Inch High Performance CNC Milling Controller Lathe Machine Controller

3. Application:

CNC lathe machinery; lathe center; wood working machine; numerically control grinder; MTDC applied to engraving CNC machine.
