Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Metal garage steel roller shutter door profile roll forming machine
Specifications
Model Number :
Tile Forming Machine
Certification :
ISO
Place of Origin :
China
MOQ :
10 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 sets / month
Delivery Time :
10-15 working days
Packaging Details :
wooden case
Brand Name :
WADJAY
Condition: :
New
Dimension(L*W*H): :
7.2*1.3*1.5m
Weight: :
About 4.5 T
Rolling thinckness: :
0.3-1mm
Roll material: :
45# high grade steel
Voltage: :
380V.50HZ.3Phase
Description

Metal stud and track garage steel roller shutter door profile roll forming machine

Product Description

Tile Type:Colored Glaze Steel
Feeding width:1220mm, 915mm, 900mm, 1200mm, 1000mm, 1250mm
Core Components:Motor, Engine, PLC
Control system:totally automatic PLC control system
Roll stations:18 rows
Shaft material:45# high grade steel
Cutting system:automatic hydyaulic cutting
Kind of drive:chain system drive
Frame material:300 H-high grade steel
Cutting blade material:Cr 12 high grade steel
Applicable Industries:Manufacturing Plant, Construction works

Metal garage steel roller shutter door profile roll forming machine

Roller Shutter Door Roll Forming Machine
1.Raw material Thickness 0.8-1.2mm
2.Decoiler Operation automatic
Weight apacity 2-5t
3.Main body Roller station 10-15 rows
Diameter of shaft 65-80mm
Material of rollers 45# steel
Material of shaft 45# steel
Frame 16-18mm
Chain 1.32-1.97inch
4.Cutter Operate auto
Blade Material cr12mov
5. Power Voltage customized
Power 4-7.5kw
6.Control system Electric Box customized/Delta
Language english chinese/customzied
7.Forming Speed Forming Speed 20-35m/min
Metal garage steel roller shutter door profile roll forming machineMetal garage steel roller shutter door profile roll forming machineMetal garage steel roller shutter door profile roll forming machine
Detailed Images

Metal garage steel roller shutter door profile roll forming machine

Metal garage steel roller shutter door profile roll forming machine
