Super Sharp Carbide Inserts For Aluminum Turning DCGT09T304 Long Tool Life

Application:

• ISO N material, the first choice for non-ferrous metal processing such as aluminum alloy.

Technical Information:

• ISO N, including non-ferrous materials and soft metals with a hardness lower than HB130, including high-strength bronze (>HB225).
• Mainly refers to aluminum alloys containing less than 12-13% Si.
• Aluminum cutting performance:
• Long chip material.
• If it is an alloy, the control of the chips is relatively easy.
• Pure aluminum is tacky, requiring sharp cutting edges and high cutting speeds.
• The cutting force is low, so the power required for processing is also low.
• If the Si content of the material is less than 7-8%, it can be processed with fine-grained uncoated carbide inserts.
• If you are processing aluminum with a high Si content, use a PCD tool.

Feature Advantage:

• Chipbreaker AL:
  • Class G precision, precision grinding of five-axis grinding machines.
  • The large rake angle and the back corner make the blade edge sharper.
  • Ensure effective chip breaking and make the cutting more brisk.
  • Surface finish to effectively prevent built-up edge, high quality machined surface and long tool life.
• Grade MN10:

• Types:
  • ISO standard turning inserts are available in a variety of conventional types
  • Different insert arcs of various specifications (R0.2, R0.4, R0.8, R1.2, etc.)

Recommended Cutting Parameters:

• The following cutting parameters are the recommended range values. Appropriate adjustments and selections should be considered after considering the following factors:
  • Specific physical properties of the material being processed
  • The actual condition of the part blank
  • Power and rigidity of the machine tool
  • Clamping rigidity of tools and workpieces
  • Balance between tool life and machining efficiency
