Specifications
Price :
negotiable
Place of Origin :
China
Brand Name :
H.SON
MOQ :
1
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Payment Terms :
Western Union, MoneyGram, T/T
Description

AT-361MYC2 Dual-Spindle Y-Axis Hard-Rail High-Efficiency Machining Lathe

Machine tool technical parameter table:
Content Units AT-361MYC2
Turret Turret specifications Model TCSM
Power turret
Turret type/Number of tools pcs BMT65-12T
Travel Maximum rotation diameter of the
hod		 mm 700
Two centroid distance mm
Z Processing length mm 1100
Maximum machining diameter mm 380
Bar processing diameter mm 75(92)
System
configuration		 FANUC OI-TF
Power tools motor KW 3.7
Spindle Oil pressure Inch 10(12)
Nose end Type A2-8
Through hole diameter mm 92(106)
Bearing type Type NN3026(3028)
Bearing diameter mm 130(140)
Spindle motor KW 11-15(guangyu)
Spindle speed rpm 3000(2500)
Secondary
spindle		 Oilpressure Inch 6寸
Nose end Type A2-5
Through hole diameter mm 45
Spindle motor KW 7.5--11
Spindle speed rpm 4500
X-axis Travel mm 230
Speed m/min 20
Servo motor Kw 3.0
Screw mm R32/10
Repeatability 0.003
Z-axis Travel mm 1100
Speed m/min 20
Servo motor Kw 3.0
Screw mm R40/10
Repeatability mm 0.007
Y-axis Travel mm 100
Speed m/min 15
Servo motor Kw 3
Screw mm R32/10
Repeatability mm 0.005
B-axis Travel mm 1100
Speed m/min 15
Servo motor Kw 3
Screw mm R40/10
Repeatability mm ±0.005
Tail seat Control mode Type
Mandrel outer diameter mm /
Morse taper Type /
X Track Type Hard track
Y Track Type Hard track
Z Track Type Hard track
Water tank capacity Liter 300

Mechanical size		 Floor area cm 355×177
Mechanica weight kg 7300
Packing size cm 400×230x228

AT-361MYC2 Machine Tool: A High - Precision Machining Solution

Product Introduction

The AT-361MYC2 is a cutting - edge machine tool engineered for complex and high - precision machining tasks. With its dual - spindle design, Y - axis integrated power turret, and hard - rail structure, it stands out in the manufacturing industry.

Product Features

Spindle Performance

  • Dual Spindles: The main spindle, powered by an 11 - 15 kW motor, reaches speeds up to 3000(2500) rpm. The secondary spindle, driven by a 7.5 - 11 kW motor, spins at 4500 rpm, enabling simultaneous operations.
  • Robust Design: Both spindles feature quality bearings (NN3026(3028)) with bearing diameters of 130(140) mm, and have substantial through - hole diameters (92(106) mm for the main and 45 mm for the secondary).

Turret Functionality

  • Power Turret: The TCSM BMT55 - 12T power turret offers 12 tool positions and a 3.7 - kW power tools motor, allowing for diverse machining options.

Axis Precision

  • X, Y, Z, B Axes: The X - axis travels 230 mm at 20 m/min with 0.003 mm repeatability. The Y - axis travels 100 mm at 15 m/min with 0.005 mm repeatability. The Z - and B - axes travel 1100 mm, with the Z - axis at 20 m/min (0.007 mm repeatability) and the B - axis at 15 m/min (±0.005 mm repeatability).

Structural Stability

  • Hard Rails: The X, Y, and Z axes are equipped with hard rails, providing excellent stability during high - speed machining.

Product Applications

Automotive Manufacturing

  • Used for producing engine components, transmission parts, and drive shafts, ensuring high - precision and mass - production capabilities.

Aerospace Engineering

  • Ideal for machining critical aerospace parts such as turbine blades and landing - gear components, meeting strict industry standards.

General Machinery Production

  • Suitable for manufacturing various mechanical parts, including shafts, gears, and connectors, in general machinery applications.
