Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems
Specifications
Material :
Aluminum Alloy 6082 T6 or Grade Specified on Drawing
Model Number :
Custom
Packaging Details :
Accept buyer's request for customized packaging
Surface Treatment :
Anodizing or Marine Suitable Finish as Specified
MOQ :
1
Delivery Time :
7-14 days
Tolerance :
±0.01mm
Certification :
ISO9001:2015
Payment Terms :
L/C,D/A,D/P,T/T
Application :
Mechanical Boat Steering Systems, Marine Rudder Assemblies
Brand Name :
Shiye
Processing :
Five Axis CNC Milling, Bore Machining, Curved Slot Machining
Place of Origin :
China
Quality Control :
CMM Inspection, Shaft Bore Measurement, Slot Profile Verification, Critical Dimension Inspection
Price :
According to the drawings
Supply Ability :
10000Pcs/ Month
Description

This custom CNC machined aluminum rudder quadrant is designed for mechanical steering systems on small commercial vessels and sailing boats, where movement from the steering cable or linkage must be transferred to the rudder shaft. Its central bore locates the part on the shaft, while the curved attachment slots accommodate the specified cable or linkage interface.
Five axis machining can help produce curved profiles, angled faces and multiple mounting features with fewer repositioning steps. Aluminum alloy selection and surface protection should account for marine exposure, load requirements and the mating shaft material.
Before production, confirm the shaft diameter, attachment method, slot geometry, steering load, corrosion protection and any required mechanical testing. The actual interface and tolerance requirements must follow the steering system drawing and design specification.

Five Axis CNC Aluminum Marine Rudder Quadrant for Boat Steering Systems

For more precision multi axis machined marine components, explore our CNC Multi-Axis Machining

For curved profiles and multi face machined geometry, see our five axis CNC machining.

Need a Similar Custom Part?

Have a drawing or CAD file for a similar component? Send us your requirements, material and quantity for a quotation. Request a CNC Machining Quote
