The HOWO 30 Ton Heavy Duty Wrecker Truck is a heavy-duty HOWO rotator tow truck designed for road rescue, vehicle recovery, towing, lifting, and accident clearance. Also known as a HOWO heavy wrecker, HOWO recovery truck, HOWO tow truck, or HOWO 30 ton wrecker, this vehicle combines a 30-ton underlift system, 50-ton telescopic boom crane, and twin 20-ton hydraulic winches on a heavy-duty HOWO chassis.

It is suitable for recovering overturned trucks, tractor-trailers, buses, construction machinery, cement mixers, and other heavy commercial vehicles. The 360-degree rotating boom allows operators to perform lifting and recovery operations from different angles, making the HOWO 30 ton wrecker particularly suitable for highway rescue, off-road vehicle extraction, and heavy accident recovery.

The HOWO 30-Ton Heavy Duty Rotator Wrecker Truck (also widely known as a Heavy Wrecker, Recovery Vehicle, or Integrated Tow Truck) is a top-tier commercial road rescue solution built for heavy-duty towing, recovery, and lifting operations. Engineered with a high-strength chassis and a robust 360-degree rotating boom system, this vehicle excels at handling severe highway accidents, overturned trucks, and heavy industrial vehicle transport.

Key Performance Highlights & Features:

Underlift System: Features a maximum underlift capacity of 30,000 kg for the superstructure (11,800 kg complete vehicle rating) and 12,500 kg at full extension (8,300 kg complete vehicle rating). With a maximum effective arm length of 3,650 mm, a telescopic stroke of 1,750 mm, and a folding angle range of -7° to +92°, it easily handles various low-clearance heavy vehicles.

Crane & Lifting System: Equipped with a powerful 3-section telescopic boom delivering a maximum lifting capacity of 50,000 kg, a maximum lifting height of 12,300 mm, and a working radius of 10,710 mm. When fully retracted at a 30° elevation angle, the boom can lift up to 18,000 kg, maintaining a 7,800 kg capacity even at full extension.

Winch System: Powered by twin hydraulic winches (2 units), each offering a rated traction force of 200 kN (~20 tons per winch). It utilizes φ20 mm x 60 m high-tensile steel wire ropes (Spec: 20-6x25Fi+IWR1870) with a minimum line speed of 5 m/min to ensure smooth, controlled pulling power.

Stabilizer & Outrigger System: Guarantees maximum stability during side-pulling and heavy lifts with an under-slung H-type front outrigger (transverse span: 6,600 mm) and an L-type rear outrigger (transverse span: 4,080 mm), offering a front-to-rear longitudinal footprint of 5,550 mm.

Applications & Usage

The HOWO 30-Ton Heavy Duty Rotator Wrecker Truck is specially designed for heavy-duty, complex road recovery and rescue operations. Its primary applications include:

• Heavy Vehicle Towing & Recovery: Towing disabled, overloaded, or damaged heavy commercial vehicles, including semi-trucks, trailers, buses, construction vehicles, and fully loaded cement mixers.

• Highway Accident Clearing: Rapidly uprighting, lifting, and clearing rollover trucks, jackknifed tractor-trailers, and fallen cargo blocks to restore normal highway traffic.
• Off-Road & Ditch Extraction: Utilizing its 360-degree rotating boom and dual 20-ton hydraulic winches to pull out vehicles that have run off the road, slid down embankments, or fallen into ditches or riverbeds.
• Heavy Lifting & Emergency Rescue : Serving as a temporary crane with up to 50 tons of lifting capacity for emergency equipment installation, debris clearing during bridge/road collapses, or disaster rescue operations.

1. Underlift System

2. Crane / Lifting System

3. Winch System

4. Outrigger / Stabilizer System

CLW AUTOMOBILE GROUP / Chengli Special Automobile supplies HOWO heavy-duty wrecker trucks for road rescue, towing and vehicle recovery applications. The 30-ton rotator wrecker can be customized according to chassis configuration, lifting capacity, boom specification, winch system, hydraulic equipment and export-market requirements.
