Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Compact MIPI CMOS Sensor Auto Focus Camera Module
Specifications
Brand Name :
SINCERE FIRST
Model Number :
SF-SY3P9A
Certification :
CE, FCC, RoHS, REACH, ISO
Place of Origin :
Guangdong , China
MOQ :
5pcs
Price :
Negotiable
Payment Terms :
L/C, Western Union, T/T, MoneyGram, Paypal and Others
Supply Ability :
350000 pcs / month
Delivery Time :
7 - 15 Work Days
Packaging Details :
Package, Carton Box
Product Name :
Samsung CMOS FPC Camera Module
Sensor Type :
S5K3P9SX04-FGX9 CMOS
Pixel :
16MP
EFL :
3.46MM
F.NO :
2.2
Focusing Type :
AF
View Angle :
D80°
Type :
16MP Camera Module
Keyword :
CMOS Camera Module
Focusing range :
10mm~∞
Description

Compact MIPI CMOS Sensor Auto Focus Camera Module

Compact MIPI CMOS Sensor Auto Focus Camera Module

Product Description:

This is compact MIPI CMOS sensor auto focus camera module integrates Samsung's advanced S5K3P9SX04-FGX9 CMOS sensor, enabling high-fidelity 16-megapixel imaging through a 1/3.1-inch optical format for precise texture reproduction in diverse environments. The module leverages a Voice Coil Motor (VCM) for swift autofocus across a 10cm to infinity range, ensuring consistent clarity with its 3.46mm focal design. Connected via an efficient MIPI interface, its miniature footprint of 8.5×8.5×5mm³ facilitates seamless integration into space-constrained electronics. This versatility supports applications from consumer devices to industrial systems, delivering real-time visual data with minimal power consumption.

Features:

  1. Enhanced Imaging Precision‌: The 1/3.1-inch sensor achieves high-definition output at 4656×3504 resolution, capturing intricate textures even in low-light scenarios.
    2. Rapid Autofocus Capability‌: Equipped with a VCM actuator, it enables sub-second focusing from close-up to distant subjects, optimizing dynamic scene capture.
    3. Streamlined Form Factor‌: Miniaturized dimensions and flexible FPC connections ensure easy deployment in compact hardware designs without compromising performance.
    4. Efficient Data Throughput‌: The MIPI interface sustains 30fps transmission at full resolution, enabling fluid video streaming for latency-sensitive tasks.

Technical Parameters:

Product Name

Samsung CMOS Sensor Mini Camera Module

Sensor

S5K3P9SX04-FGX9

Piexl16MP

F.NO

2.2

Output Interface:

MIPI

EFL

3.46mm

Keywords

CMOS Camera Module

Warranty

10 Years

Focusing Range

10cm~Infinity

Brand Name

SINCEREFIRST

Applications:

Mobile Photography‌: Enhances smartphone imaging with robust low-light performance, allowing users to record vivid moments in varying conditions.
Aerial Imaging Systems‌: Lightweight construction and rapid focus adapt to drone gimbals, supporting stable aerial footage during high-motion flights.
Medical Diagnostics‌: High-resolution capture aids dental 3D scanners in detailing oral structures, improving diagnostic accuracy for treatments.
Security Solutions‌: Wide focus range covers entryway surveillance for smart locks, delivering sharp visuals for real-time monitoring.
Biometric Authentication‌: Short focal length ensures reliable face or iris recognition across environments, enhancing security systems.
Compact MIPI CMOS Sensor Auto Focus Camera Module

Customized Process:

1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.

About US:

Compact MIPI CMOS Sensor Auto Focus Camera Module

Cooperative Brands & Customers:

Compact MIPI CMOS Sensor Auto Focus Camera Module

Why Chooes US:

Compact MIPI CMOS Sensor Auto Focus Camera Module

Detail Pictures:

Compact MIPI CMOS Sensor Auto Focus Camera ModuleCompact MIPI CMOS Sensor Auto Focus Camera ModuleCompact MIPI CMOS Sensor Auto Focus Camera Module
