1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices
Specifications
Payment Terms :
L/C, Western Union, T/T, MoneyGram, Paypal and Others
Pixel :
1MP
Sensor Size :
1/4 inch
Pixel Size :
2.8µm × 2.8µm
Model Number :
SF-SQ1A47
Max MJPG Output :
1280×720@30fps
MOQ :
5pcs
Delivery Time :
7 - 15 Work Days
Output Format :
MJPG / YUY2
Price :
Negotiable
Module Size :
38×38mm ±1mm
Certification :
CE, FCC, RoHS, REACH, ISO
VGA Output :
640×480@30fps MJPG / 25fps YUY2
Supply Ability :
350000 pcs / month
Product Name :
USB2.0 CMOS Camera Module
Interface :
USB2.0 High Speed
Place of Origin :
Guangdong , China
Connector :
4-pin 2.0mm Terminal Connector
Brand Name :
SINCERE FIRST
Focus Range :
1cm–∞
Packaging Details :
Package, Carton Box
Description

1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices

1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices

Product Description:

This is 1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices.It supports 1280×720@30fps in MJPG mode, uses a 38×38mm PCB, and operates at only 80mA. It also supports development environments such as Windows DirectShow, Halcon, OpenCV and LabView, making it suitable for testing, prototyping and practical low-cost USB camera products.

Choose this model when your project needs simple 720P USB image capture, low power consumption and easy software access.

Features:

1. 1MP 720P Image Capture: 1280×720@30fps in MJPG mode is suitable for basic video preview, image capture and simple visual checking.

2. Low 80mA Operating Current: The low operating current helps support compact and power-sensitive USB devices.

3. USB2.0 UVC Driver-Free Design: UVC support allows easier integration with common USB host devices and image acquisition software.

4. Development-Friendly Platform: Support for DirectShow, OpenCV, Halcon and LabView makes this module suitable for development, testing and machine vision learning projects.

5. Flexible Lens Options: Lens options include 1.8mm, 2.8mm, 3.6mm, 6mm, 8mm, 12mm and 16mm for different viewing needs.

6. Optional Housing Support: Industrial camera housing, square metal housing and plastic housing directions can be evaluated for product assembly.

Technical Parameters:

Product Name

USB2.0 CMOS Camera Module

Sensor

CMOS

Piexl 1MP

Resolution

1280×720@30fps

Output Interface

 USB2.0

Sensor Size

1/4 Inch

Pixel Size

2.8µm × 2.8µm

Output Format

MJPG / YUY2

Connector

 4-pin 2.0mm Terminal Connector

Keywords

CMOS Camera Module

Warranty

10 Years

Focusing Range

1cm~Infinity

Brand Name

SINCEREFIRST

Applications:

1. Smart Terminals & Kiosk Cameras: For smart terminals, self-service kiosks and access devices, this module provides a simple USB camera solution for basic video preview, user interaction and image capture. Customers choose it when they need stable 720P imaging, low power consumption and easy USB integration.

2. Barcode & QR Code Reading Devices: For entry-level barcode and QR code readers, this camera module can provide practical image input for code capture and recognition. It is suitable for customers who need a cost-effective camera module for fixed-distance scanning or simple recognition tasks.

3. Industrial Visual Checking Tools: For simple inspection tools and equipment status checking, this module helps users view object position, surface condition or device status in real time. Customers choose it when the project does not require high resolution but needs reliable image feedback and easy system connection.

4. OpenCV / LabView Development Projects: For development, testing and machine vision learning projects, the module is easy to use with common visual software environments. It is suitable for engineers who need a low-cost USB camera module for image acquisition, algorithm testing and prototype development.

5. Embedded USB Vision Devices: For embedded USB vision terminals, smart cabinets and compact visual devices, this model offers a practical balance between 720P image quality, low current consumption and flexible lens options.

1MP USB2.0 UVC Camera Module with 720P30 Output for Cost-Effective Vision Devices

Customized Process:

1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.
