Clion HHS1 Time Delay Relay for AC/DC Control Circuit with Large Control Capacity and Incremental/Decremental Display Timing
Clion HHS1 Time Delay Relay for AC/DC Control Circuit with Large Control Capacity and Incremental/Decremental Display Timing
Clion HHS1 Time Delay Relay for AC/DC Control Circuit with Large Control Capacity and Incremental/Decremental Display Timing
Clion HHS1 Time Delay Relay for AC/DC Control Circuit with Large Control Capacity and Incremental/Decremental Display Timing
Clion HHS1 Time Delay Relay for AC/DC Control Circuit with Large Control Capacity and Incremental/Decremental Display Timing
Clion HHS1 Time Delay Relay for AC/DC Control Circuit with Large Control Capacity and Incremental/Decremental Display Timing
Specifications
Brand Name :
Clion
Model Number :
HHS18
Place of Origin :
China
Item No. :
HHS1-1(DH14S)
Hole Size :
45×77mm
Installation :
Panel Type
Delay Range :
0.01S~99h99m
Dimension :
52× 104× 110mm
Description

HHS1 Time Relay


HHS1 (improved) series time relay belongs to the power-on time-delay type, suitable for AC 50Hz, working voltage 380V and below or DC working voltage 24V control circuit as a time-delay element, according to the preset time to connect or break the circuit.

The relay adopts special timing chip, which has the advantages of high delay precision, wide delay range, large control capacity, low power consumption, light touch switch setting, dynamic display, and can achieve the advantages of incremental or decremental display timing.

This series of relays meets the requirements of GB/T14048.5.

Ordering Information

Specification HHS1-1(DH14S)
Operating power DC24V;AC24V,AC220V,AC380V
Delay range 0.01S~99h99m
Repeat Error ≤ 1%
Contact Form Two delay with reset pause (11 pins)
Temperature range -5°-40°C
Altitude ≤2000m
