Specifications
Brand Name :
KOMEG
Model Number :
KMH-408
Certification :
CE; ISO 9001; ISO 14001
Place of Origin :
Guangdong,China(Mainland)
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 per month
Delivery Time :
35 work days
Packaging Details :
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Volume :
408L
Interior Dimension(cm) :
width:70 height:75 deep:80
Exterior Dimension :
width:98 height:194 deep:174
Temp.range :
-70°C~+150°C
Humidity range :
20~98%R.H
System :
Balanced&Humidity Control System
Power :
AC 380V/50Hz 3 Phase 4 Wires+Ground Wires
warranty :
1 year
Description

Electronics Lab Equipment / Temperature & Humidity Testing Chamber For Industrial

Product Description

Electronics Lab Equipment / Temperature & Humidity Testing Chamber For Industrial is simulation under the condition of product in humid climate environment combination

(high and low temperature operation & storage, temperature cycle, high temperature and high humidity, low temperature and humidity and condensation test, etc.), check whether the adaptability and characteristics of the product itself.

Product Specification

Environmental Temperature and Humidity Chamber
Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load)
Model KMH-L series
408L
Temp. range -40 ºC~+150ºC
Interior sizel W(mm) 700
H(mm) 750
D(mm) 800
Exterior size W(mm) 980
H(mm) 1940
D(mm) 1740
Power(KW) 8.5
Weight(KG) 420
Humidity uniformity ±3.0%R.H
Heat up time -40ºC~+100ºC, within 45 min
Pull down time +20ºC~-40ºC , within 60 min
Standard accessories Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m
Safety device (standard) No fuse breaker, over pressureover heat and over current protection for compressor,
Over temp. protect, over load protect of blower, dry heat protection
Control System Balanced Temperature & Humidity Control System
Refrigeration system Air Cooled (Water Cooled Type is option)
Hermetic compressor,Single stage refrigeration system
CFC-Free refrigerant(HFC-507/HFC-23)
Controller Panel:7-inch LCD Touch panel, Chinese or English display selectable
Operation model :Program or fix point running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles
Humidity Range 20~98%R.H
Temp. constancy ±0.5ºC
Humidity constancy ±2.5%R.H
Temp. uniformity ±2.0ºC
Interior material Stainless Steel Plate(SUS 304)
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid polyurethane Foam and Glass Fiber Wool
Ambient Temp. +5ºC~+35ºC
Wiring method AC 380±10%50Hz ,3 phase 4 wires +Ground Wires
Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available

Feature

1. Use the high precision microcomputer touch temperature and humidity controller with high stability

of platinum resistan-ce to temperature and wind speed in the circulatory system of temperature and

humidity test.

2. Control temperature&humidity well-distributed, precisely and steady.

3. Completely independent system separate for testing in high temperature, low temperature and constant

temperature & humidity environment.

Products

Refrigeration System Climatic Testing Chamber 408L Blue And Grey 1 Year Warranty

Refrigeration System Climatic Testing Chamber 408L Blue And Grey 1 Year Warranty

Oversea client

Refrigeration System Climatic Testing Chamber 408L Blue And Grey 1 Year Warranty

Our service

1. Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.

2. Good Packaging:

Each set protected with resin fiber and PP film, then put into strong plywood case with operation mannual inside.
