Specifications
Brand Name :
KOMEG
Model Number :
KMHW-13
Certification :
CE/ROHS/FCC/
Place of Origin :
China
MOQ :
1set
Price :
negotiation
Payment Terms :
T/T /C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
50 sets per month
Delivery Time :
42 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Product Name :
Drive-in Walk-in Test Chambers
Application :
reliability testing, research & development testing, failure analysis
Volume(M3) :
27.1CBM
Door Size :
Single Wing:W80*H180;Double Wing:W160*H180
Temp. Constancy :
+/-0.5oc
Humidity Constancy :
+/-2.5%R.H
H.S. Code :
90321000
Delivery :
42 working days
Installation :
Yes
Description

Stainless Steel Material 27.1 Cubic Customized Walk-in Environmental Test Chamber

1. Applications

Whether you're testing computers and copiers or automobiles and satellites, KOMEG's Walk-In Environmental Test Chambers provide solutions that work. Capable of testing large components, assemblies, and finished products, KOMEG's Walk-In chambers simulate a wide range of temperature and humidity environments. These chambers can be used for testing and controlled storage as well as a versatile laboratory environment for conducting test procedures in the telecommunications, defense, aerospace, pharmaceutical, automotive, and electronics industries.

2. Standard Implemented and Met:

Inspect standard: JJF-1101, GB/T 10592,GB/T 10586

Testing standards:

YD/T 2061, HB 7122.3, 6783.7, GJB 5382.7, GJB 150, GB/T 2423,5170.2,5170.5,5179.2, ASTM E512, NF EN 60068-2-38, CNS 12565,12566, KS C0227, KS C022

3. Main Technical Parameters

Model KMHW-13
Volume(m³) 27.1CBM
Interior Dimensions W3000 x H2100 x D4300mm
Exterior Dimensions W5050 x H2350 x D2250mm
Safety Devices(standard) No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection
Standard accessories Sight window*1, cable port ( portΦ50mm ) *1, chamber lamp*1, status indicator
Control System Balanced Temperature & Humidity Control System
Refrigeration system Water Cooled
Semi-hermetic compressor, single stage or cascade refrigeration system,
CFC free refrigerant ( HFC-507 and HFC-23 )
Controller Panel 7-inch LCD Touch panel, Chinese or English display selectable
Operation model Program or fix point running
Memory capacity 120 programs,1200steps, all repeat 999 cycles,part repeat 99 cycles
Accuracy Temp.:0.1% of F.S ± 1 digit Humidity:0.1% of F.S ± 1 digit
Input Temp.: pt-100, Humidity: pt-100 or ～5V DCV
Comm.port RS-232 or RS-485 ( Softawre is option)
Temp. range Maximum: 80 ºC,120 ºC;
Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC
Humidity Range 10%, 20%, 30% ~ 95%
Temp. constancy ±0.5 ºC
Humidity constancy ±2.5%R.H
Temp. uniformity ±2.0 ºC
Humidity uniformity ±5.0%R.H
Ambient Temp. +5 ºC～+35 ºC
Wiring method AC 380 ± 10% 50Hz ,3 phase 4 wires + Ground Wires
Heat up time +20 ºC～+80 ºC, Within 60 min
Pull down time +20 ºC ~ -55 º, -40 ºC, -20 ºC, -10 ºC, Within 120 or 90 or 60 min
Interior material Stainless Steel Plate(SUS 304)
Exterior material Baked Painting Steel Or Stainless steel ( SUS304)
Insulation material Rigid polyurethane foam
Door size (mm) Single wing: W800 x H1800; Double wing: W1600 x H1800;
Note:1. We reserve the right to change specifications without prior notice 2.Customized sizes and configurations available

4. Description

Flexibility for structure

The panels used in our chamber are 4” (100mm or 150mm) Thick urethane-foam sandwiched between a stainless-steel interior wall and a coated-steel exterior. An assembled box is self-supporting. So that no heavy structural members are required. Different door sizes, flooring upgrades,access ports, and other modifications are possible.

Widest test range, most customizable
