Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials
Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials
Specifications
Brand Name :
KOMEG
Model Number :
KMH
Certification :
CE
Place of Origin :
GUANGDONG, CHINA
MOQ :
1set
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
500 Set/Sets per Year thermal shock test machine
Delivery Time :
Shipped in 45 days upon your deposit
Packaging Details :
Each set protected with resin fiber and PP film, then put into strong plywood case with operation mannual inside.
Products Name :
KMH-1500L Programmable Temperature And Humidity Chamber
Application :
electronic products to do the heat and cold resistance test
Material :
Stainless Steel Plate (SUS304)
Refrigeration System :
air cooled and water cooled for option
Test. chamber :
-40 °C~ +150°C
Controller :
LCD Touch Screen
Power supply :
AC 380V/50Hz 3 Phase 4 Wires+Ground Wires
Description

Machinery Equipment Temperature and Humidity Chamber Used In Industrial

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

KOMEG Programmable Temperature and Humidity Chamber used for inspecting the equipment and testing the performance of materials in various environments and all kinds of materials which need to test the heat resistance,cold restance,dry resistance and moisture resistance. for

It's applicable for computer,TV,mobile phone,monitors,printers,fax and other electronic products to do the whole heat and cold resistance test.

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

Programmable Temperature and Humidity Chamber
Specifications used for inspecting the equipment and testing the performance of materials have the properties of heat,cold,dry and moisture resistance,which is applicable for electronic products.
Model KMH-1500L
Interior size W(mm) 1000
H(mm) 1500
D(mm) 1000
Exterior size W(mm) 1550
H(mm) 1895
D(mm) 2230
Temp. range

-40ºC~+150ºC

Temperature Deviation ≤±2.0ºC
Temperature Fluctuation

Heating Rate :from + 20ºC to + 150ºC ≤ 60min (with load)

cooling :form + 20ºC to -40ºC ≤ 40min (with load)

Humidity range 20~98%R.H
Humidity fluctuation ±2.0%R.H
System
Balanced & Humidity Control System
Lighting device One light of 11W/AC220V,located on observation window
Standard accessory Observation Window*1,cable port(port^50mm)*2,shelves*2,chamber lamp*1,power cable 2 m
Interior material Stainless steel plate(SUS 304)
Exterior material Baked painting steel or stainless steel(SUS304)
Insulation material Rigid polyurethane Foam+glass fiber wool
Refrigeration system Air cooled and Water Cooled for option
Hermetic compressor,stage refrigeration system
Controller

Touch screen controller Chinese,English,Russian menu Operation mode :setting/program

Hermetic Compressor,Cascsde Refrigeration CFC free refrigerant
Ambient Temp. +5ºC~+35ºC
Power AC 380±10%50Hz ,3 phase 4 wires +Ground Wires

Structure Features

Wall material:Top-grade Carbon Steel Plate,Surface electrostatic color Spray processing

Inner wall material:Stainless Steel Plate SUS304

Body insulation material:Rigid polyurethane Foam + glass fiber

Door insulation material:Rigid Polyurethane Foam + Glass fiber

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of MaterialsProgrammable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of MaterialsProgrammable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

Why Choose KOMEG?

Over 28 Years' Experience
Komeg has been the brand of Komeg Technology Industrial since 1990. We manufacture environmental simulation test equipment for quality-conscious customers. Our factory is located in Dongguan, covering an area of 5,000 square meters, with over 52 employees including 26 R&D engineers.

Besides this, we have a lot of other chamber for your reference:
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. And Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Two wing Drop Tester
Vibration Testing Machine( mechanical and electromagnetic)

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

Programmable Wet Heat Alternating Environmental Test Chamber To Test The Performanc Of Materials

Packing
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 T
Packing Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special requirments.
