Specifications
Brand Name :
KOMEG
Model Number :
ESS-225S-C15
Certification :
CE ISO9001
Place of Origin :
China
MOQ :
1Set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 Set/Sets per Year
Delivery Time :
25-35 work days
Packaging Details :
Packed by PP firstly, and then reinforced with plywood case for outer packing
Temperature Range :
-70 ºC～+100 ºC( Rapid Temp Change -55 ºC～+85 ºC Full Linear Control)
Humidity Constancy :
±0.5 ºC
Temp Constancy :
±3.0 ºC
Interior Material :
Stainless Steel Plate（SUS 304）
Exterior Material :
Cold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless Steel
Insulation Material :
Rigid Polyurethane Foam
Description

225L Single Door High Reliability Intelligent Rapid Change Temperature

Applications

Temperature adaptability test under the condition of rapid change, or gradient for electrical, electronic,

instruments and other products or spare parts, particularly applies to environmental stress screening

test (ESS)

Environmental stress screening (ESS) refers to the process of exposing a newly manufactured or

repaired product or component (typically electronic) to stresses such as thermal cycling and vibration in

order to force latent defects to manifest themselves by permanent or catastrophic failure during the

screening process. The surviving population, upon completion of screening, can be assumed to have a

higher reliability than a similar unscreened population.

ESS can be performed as part of the manufacturing process or it can be used in new product

qualification testing.

Features

Rational Construction and fast cooling rate

Frequency conversion control of wind speed.

Adopts international brand of imported parts for cooling system to improve operation reliability

Touch screen controller, friendly Man-Machine interface and safety device to ensure simple operation

and easy maintenance.

Wide variety of refrigeration available for performance and temperature range flexibility.

Programmable LCD touchscreen controller for product or air-change available.

Specifications

Model ESS-S
225SC15
Working Chamber Volume(L) 225L
Temp Rate of Change( ºC /Min) 5 ºC /Min
Temperature Range -70 ºC～+100 ºC( Rapid Temp Change -55 ºC～+85 ºC Full Linear Control)
Humidity Constancy ±0.5 ºC
Temp Constancy ±3.0 ºC
Exterior Material Cold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless Steel
Interior Material Stainless Steel Plate(SUS 304)
Insulation Material Rigid Polyurethane Foam
Safety Devices over pressure,over heat and over current protection for compressor, over temp. protection,
Compressor Semi-Hermetic Compressor
Cooling Mode Water Cooled
Control system Balanced Temperature & Humidity Control System(BTC type)
Heater Iron-chrome wire heater
Blower Centrifugal Blower
Observation Window Glass incorporating heat generator
Temp Sensor Pt-100
Controller Touch screen programmable controller
Ambient Temp. +5ºC~+35ºC
Power AC 380V/50Hz 3phase 5 wires+ Ground wire
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available

Features

GB10592-89 Technical requirements for high and low temperature test chamber

GB2423.1-1989 Low temperature test

GB2423.2-1989 High temperature test mode

Prouduct Display

225L Single Door ESS Chamber High Reliability Intelligent Rapid Change Temperature

225L Single Door ESS Chamber High Reliability Intelligent Rapid Change Temperature

Packing and Shipment:

(1).Strong standard wood case, inner plastic films wrapped for temperature and humidity test chamber
(2).Usually we delivery the equipment by air,by sea or by express. it depends on customer.
225L Single Door ESS Chamber High Reliability Intelligent Rapid Change Temperature
Pre-sales service

1) More than 20 years manufacturer experience and 8 years export experience.
2) Acceptable customization for all kinds of special specification products.
3) We value very inquiry sent to us, ensure quick and competitive offer.
4) We put your order into our tight production schedule,ensure your punctual delivery time.
5) We are a sales team, with more than 4 years experience, more professional and reliable.
6) Welcome to view our factory at any moment .
After-sales service

1) We deal with your complains within 24 hours.
2) Training how to install the machine, training how to use the machine.
3) Engineers available to service machinery overseas.
4) All staffs in our company with philosophy of " integrity, dedication, truth-seeking, enterprise", would be
dedicated to provide high quality service and products for you.
