Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Specifications
Brand Name :
ASLi
Model Number :
UV Series
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100 sets per month
Delivery Time :
20-25 days
Packaging Details :
standard export
Product Name :
Simulated UV Aging Climatie Resistant Test Chamber With CE Certification
Internal Dimension (mm) :
1150x500x400
External Dimension (mm) :
1500x1500x550
Applicable Standard :
GB/T16422,GB/T5170.9
Temperature Range :
R.T.+10℃~+70℃
Power :
AC220V
Description

UV Light Aging Test Chamber UV-290.pdf


Simulated UV Aging Climatie Resistant Test Chamber With CE Certification

Test Requirement:

Method: Put the specimens into the UV aging chamber according national standard and IEC61215 UL1703,using 340nm wavelength UV for component and raw materialradiation.

Technical Parameters:

Model UV-290
Internal Dimension WxHxD (mm) 1150x500x400
External Dimension WxHxD (mm) 1500x1500x550
ApplicableStandard GB/T16422,GB/T5170.9
TemperatureRange R.T.+10℃~+70℃
Temperature Fluctuation ±0.5℃
HumidityRange ≥95%R.H.
Environmental Temperature for Use +5℃~+35℃
Test Light Source UVA,UVB UV light
Wave Length of
Test light Source (nm)		 280~400
Center Distance
between Sample and Tube (mm)		 50±2
Center Distance
Between Tubes (mm)		 75±2
Material of Internal Case Stainless steel with sanding polish
Material of External Case Stainless steel with sanding polish or painting coated
Heating the Humidifier Electric-heat type steam generator ,heating and humidification
Safety System Operation Interface Digital smarts touch key input (Programmable)
Running Mode Program/constant running type
Input Black panel thermometer.PT-100 Sensor
Standard Configuration 1 pc Stainless steel shelves
Safety Configuration Protection of electric leakage, power outage when over-load, over-temperature protection, water short storage, touch the ground protection
Power AC220V 1∮3 lines, 50HZ

Simulated UV Aging Climatie Resistant Test Chamber With CE Certification

Application:


UV Climate Resistant Aging Test Chamber simulates the sunlight damage on the material and product, it is widely used in the evaluation of material climate resistantance.

More Pictures for reference:

Simulated UV Aging Climatie Resistant Test Chamber With CE Certification

Simulated UV Aging Climatie Resistant Test Chamber With CE Certification :

1.Professional Manufacturer

2.Operation easy

3.Customized Size

4. Fast Delivery



We are looking forward to doing more business at home and abroad. If you are interested in our products,please feel free to contact us ! And warmly welcome our new and regular customers visit our factory !
