Replaceable Gel Seal Hepa Filter Diffuser , 250mm Air Inlet Size Laminar Flow Diffusers
Replaceable Gel Seal Hepa Filter Diffuser , 250mm Air Inlet Size Laminar Flow Diffusers
Replaceable Gel Seal Hepa Filter Diffuser , 250mm Air Inlet Size Laminar Flow Diffusers
Replaceable Gel Seal Hepa Filter Diffuser , 250mm Air Inlet Size Laminar Flow Diffusers
Specifications
Brand Name :
XNGK
Model Number :
XN-AD
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
1000 Sets per month
Delivery Time :
10-15 working days
Packaging Details :
carton box , wooden case
Frame :
Stainless steel, painted steel, galvanized steel
Efficiency :
H13 or H14
Size :
Customized
Filter material :
Glass fiber HV
Seal :
Gel Seal or Neoprene
Air flow rate :
500-4000CMH customized
Description

Replaceable Gel Seal HEPA Laminar Flow Diffusers for Clean Room

Specifications:

  • Gel seal HEPA filter H13, H14 Efficiency EN:1822
  • Coated cold roll steel frame;
  • Perforated panel air outlet;
  • Customized size;
  • Air inlet size: 250mm, 300mm, 350mm;
  • Anodized frame for HEPA filters, painted metal mesh faceguard;
  • DOP PAO test;
  • Butterfly damper adjustable the air volume;

The replaceable gel seal HEPA laminar flow diffuser is mainly designed for cleanroom in pharmaceutical, hospital operating room, food processing, LED, micron electronics, optical, bio-technology industries.

Also, it`s very good design for commercial & Industries buildings.

To maximize the service life of gel seal HEPA laminar flow diffuser filters. It`s quite necessary to add medium pocket filter or V bank filter before HEPA filtration.

Advantageous:

Butterfly damper adjustable for revising the air flow rate from roomside; gel seal gasket sealed the HEPA filter with diffuser housing perfectly.

DOP PAO test to make sure no air leakage.

Replaceable Gel Seal Hepa Filter Diffuser , 250mm Air Inlet Size Laminar Flow Diffusers
