Specifications
Brand Name :
BBT
Model Number :
EV50A
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 set clay brick making extruder
Price :
Refer to quotation sheet
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 sets brick extruder machine per month
Delivery Time :
2 weeks
Packaging Details :
Clay Brick Making Machine by container sea shipment
Brick equipment :
Clay Brick Making Machine Automatic High Efficiency for Sale | Industrial Use
Advantages :
2025 Hot Sale Clay Brick Making Machine - Low Cost & High Output
Machine capacity :
10,000-13,000pcs/h（250*110*75mm）
Machine power :
160+55kw
Extruder size :
Upper stage: 4,400*2,200*1,250mm Lower stage: 5,600*1,800*2,500mm
Machine weight :
17,500kg
Description

Clay Brick Making Machine Automatic High Efficiency for Sale | Industrial Use

2025 Hot Sale Clay Brick Making Machine - Low Cost & High Output

Clay Brick Making Machine Automatic High Efficiency for Sale | Industrial Use

Equipment Introduction :

This machine is suitable for continuous extrusion of wet clay and serves as a key functional equipment in the molding section of the brick production line. The mud bar extruded by this equipment features a smooth and compact surface, excellent quality, large extrusion output, easy operation, stable running and high reliability.
It can produce various types of bricks, including solid bricks, hollow bricks, porous bricks and hollow blocks. The machine is composed of three parts: upper mixing part, vacuuming part and lower extruding part.
Clay Brick Making Machine Automatic High Efficiency for Sale | Industrial Use
Clay brick making line machine vacuum extruder of technical datas:
No. Model EV50A
1 Code IBS062-0205
2 Production capacity 10,000-13,000pcs/h(250*110*75mm)
3 Extrusion pressure ≤3.0Mpa
4 Vacuum degree ≤-0.092
5 Rotate speed of extruding shaft 25rpm
6 Diameter of reamer

Material transporting part :500mm

Extruding part :450mm
7 Vacuum pump 2SK-6
8 Reducer

Upper stage:i=12.64

Lower stage :i=21.3
9 Triangle belt

Upper stage:5V-4600*6

Lower stage:5V4800*10
10 Power 160+55kw
11 Dimension

Upper stage: 4,400*2,200*1,250mm

Lower stage: 5,600*1,800*2,500mm
12 Weight 17,500kg

Clay Brick Making Machine Automatic High Efficiency for Sale | Industrial Use

Key Features & Capabilities:

  • Manufactures bricks and blocks in diverse sizes and specifications.
  • Accommodates a wide range of raw materials, including clay, mud, soil, fly ash, shale, and more.
  • Compatible with various drying systems: tunnel dryer, single-layer chamber dryer, high-speed rapid dryer.
  • Supports multiple firing solutions: tunnel kiln and custom local kiln.
  • Equipped with an integrated automatic brick stacking system.
  • Features high-output brick molding machinery for complete production lines.
  • Offers flexible fuel selection: coal, gas, oil, and other energy sources.
  • Daily production capacity ranges from 50,000 to 100,000 bricks; higher output models available upon request.
