Specifications
Brand Name :
Brictec
Model Number :
BRICTEC
Certification :
CE; ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 194100 -210000$
Payment Terms :
D/A,L/C,D/P,T/T,Western Union
Delivery Time :
30 days
Type :
Raw Material Processing
Application :
Brick Making
Function :
Green brick cutting and column cutting
Bricks Materials :
clay, mud, soil , fly ash , coal shale
Description
Equipment Introduction

The Ultra-Fine Roll Crusher is a high-efficiency grinding equipment for clay brick production. It utilizes two precision rollers with micron-level gap adjustment to crush raw materials (e.g., clay, shale) into uniform particles of 0.5-3mm, significantly improving the quality of subsequent mixing and extrusion processes.

Automatic Fine Roller Mill Clay Brick Making Machine Raw Material Crusher Clay Crushing Machine Stone Crusher Smoothly Clay Making Machine
Technical Data
Model Capacity(t/h) Roller size(mm) Input size(mm) Output size(mm) Dimension(mm) Weight(t) Power(kW)
SGS800*800 30-50 Φ800*800 ≤10 0.8-1.5 4000*4000*2200 18 75+55
SGS1000*1200 40-80 Φ1000*1200 ≤10 0.8-1.5 4500*4800*2500 31 132+90
Automatic Fine Roller Mill Clay Brick Making Machine Raw Material Crusher Clay Crushing Machine Stone Crusher Smoothly Clay Making Machine
Features
  • Ultra-Fine Crushing: Unique roller surface texture + high-pressure grinding for output fineness ≥0.5mm.
  • Precision Gap Control: Hydraulic/servo system adjusts roller gap (0.1-5mm) with ±0.05mm accuracy.
  • Wear-Resistant Rollers: Tungsten carbide or ceramic-coated rollers, 3x longer lifespan than standard alloy rollers.
  • Fully Enclosed Design: Dust extraction ports comply with environmental standards.
Automatic Fine Roller Mill Clay Brick Making Machine Raw Material Crusher Clay Crushing Machine Stone Crusher Smoothly Clay Making Machine
Function

Replaces traditional two-stage crushing (jaw crusher + hammer crusher) with single-pass ultra-fine grinding, preventing over-crushing and ensuring optimal clay gradation to minimize brick drying cracks.

Advantages
  • 30% Energy Saving: Power consumption ≤3.5kWh per ton, lower than traditional crushing lines.
  • Uniform Output: 90% particles in 0.5-2mm range, reducing extruder jamming risks.
  • Low Maintenance: Modular roller design allows replacement within 2 hours.
Automatic Fine Roller Mill Clay Brick Making Machine Raw Material Crusher Clay Crushing Machine Stone Crusher Smoothly Clay Making Machine
Key Technical Terms

Ultra-Fine Roll Crusher • Roller Gap Adjustment • Tungsten Carbide Roller Sleeve • Particle Gradation
