Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
Specifications
Type :
SCART
Application :
Audio & Video
Gender :
Male
Connector type :
100% compatible connector
Shell size :
1031series
Molti-pole :
10,12,19 pins
Contacts (straight or elbow) :
Solder, print or crimp
Outer shell plated :
chrome-plated brass
contact plated :
brass with gold-plated
insulator :
PPS
Protection level :
IP68
Certificate :
CE ROHS ISO9001 SGS
Port :
Shenzhen
Certification :
CE ROHS2.0 REACH ISO:9001-2015
Place of Origin :
Guangdong, China
Brand Name :
RAYMO
Model Number :
S SS WSO 1031 A010-130
Supply Ability :
5000 Piece/Pieces per Week
Packaging Details :
150 pcs per 18*15*10 carton
MOQ :
10 Piece/Pieces
Price :
Negotiable
Description

Prct Description
S SS WSO 1031 A010 - 130+ 12 pin circular audio video aviation connectors
Waterproof push pull connector
cable assembly solutions
oem connector design
Shell size and Contact no we do have:

Connector Type Overview Shell size Contact no.
S/SS/SSC/WSO 102/0F 2 3 4 5 7 9 　 　 　 　 　
103/1F 2 3 4 5 6 7 8 10 12 14 16
1031/AF 10 12 15 (traxial) 19 　 　 　 　 　 　 　
104/2F 2 4 6 8 9 16 19 　 　 　 　
Technical characteristics
Pulling and inserting times ＞5000 times
Humidity Maximum humidity up to 95% at a temperature of 60 °
Temperature range - 65° C, +200° C
Vibration 15 g [10 Hz - 2000 Hz]
Shock Resistance 100 g [ 6 ms]
Salt Cpray Corrosion test >96hr
Protention Level IP 68
Connector Type Socket, female pins
Number of positions 1-32pin
Contact Terminal Solder
Fastensing Type Push-pull
Shell Material Brass
Shell Finish Chrome Plated
Shell Colour Silver, Black
Contact Material Brass
Contact finish Gold
Insert Material PPS, PEEK
Our Company

RAYMO is a manufactuer that:
• Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
• Can be 100% compatible with original LEMOS • FISCHERS • S • HIROSES • BINDERS •Industrial 38999
• Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,
B423, 38999, 26482
• CO, Form A, Form E for customer clearance
• CE, ROHS, ISO:90001-2008, SGA Audited manufacturer
• All the items can work normally after 5000times mating

Certifications
  • CE
  • RoHS2.0
  • SGS
  • ISO:9001-2015
  • Reach
Packing & Delivery

Connector: 120pcs in 18*15*10cm carton box
Cable: 100pcs in 33*20*23cm carton box

1-300pcs:3-5 working days.
301-500pcs: 5-7 working days.
501-1000pcs: 7-10 working days.
OEM prct: 40-50 working days.

FAQ

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
We are SGS audited manufacuter, passed ISO9001-2008 Quality managerment system,
and served global customers as a trusted supplier for more than 4 years. All the prcts meet CE ROHS standards.
2. What is the MOQ?
Raymo: No MOQ limited, depond on customer real needs.
3. Free sample:
RAYMO: Avaible. Any needs, pls contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5.What is your payment terms?
Raymo: 100% T/T deposite when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

Photos

Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design

Audio Video Aviation Plug Connector High Accuracy Black Color Male OEM Design
