Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode
Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode
Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode
Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode
Specifications
Brand Name :
ANPEC
Model Number :
APM4953KC-TRG
Certification :
Original Factory Pack
Place of Origin :
Philippines
MOQ :
20
Price :
Negotiate
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
20000
Delivery Time :
1
Packaging Details :
please contact me for details
Features :
-30V/-4.9A ,
Features2 :
RDS(ON)=53mΩ(typ.) @ VGS=-10V
Features3 :
RDS(ON)=80mΩ(typ.) @ VGS=-4.5V
Features4 :
• Super High Dense Cell Design
Features5 :
Reliable and Rugged
Features6 :
SOP-8 Package
Description

 Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode

  Feature

• -30V/-4.9A ,

RDS(ON)=53mΩ(typ.) @ VGS=-10V

RDS(ON)=80mΩ(typ.) @ VGS=-4.5V

• Super High Dense Cell Design

• Reliable and Rugged

• SOP-8 Package

• Lead Free Available (RoHS Compliant)

Application:

• Power Management in Notebook Computer, Portable Equipment and Battery Powered Systems

Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode  Note: ANPEC lead-free products contain molding compounds/die attach materials and 100% matte in plate termination finish; which are fully compliant with RoHS and compatible with both SnPb and lead-free soldiering operations. ANPEC lead-free products meet or exceed the lead-free requirements of IPC/JEDEC J STD-020C for MSL classification at lead-free peak reflow temperature.

Symbol Parameter Rating Unit
VDSS Drain-Source Voltage -30 V
VGSS Gate-Source Voltage ±25
ID* Continuous Drain Current VGS=-10V -4.9 A
IDM* Pulsed Drain Current VGS=-10V -20 A
IS* Diode Continuous Forward Current -2 A
TJ Maximum Junction Temperature 150 °C
TSTG Storage Temperature Range -55 to 150
PD* Power Dissipation for Single OperationTA=25°C 2 W
Power Dissipation for Single Operation TA=100°C 0.8
RθJA* Thermal Resistance-Junction to Ambient 62.5 °C/W

Typical Characteristic

Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode Digital IC Circuits APM4953K  Dual P Channel Enhancement Mode
