RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
Specifications
Brand Name :
VISHAY
Model Number :
BYG23M-E3-TR
Certification :
Original Factory Pack
Place of Origin :
Malaysia
MOQ :
5pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
1200PCS
Delivery Time :
1 Day
Packaging Details :
please contact me for details
package :
Low profile package
Application :
Ideal for automated placement
junction :
Glass passivated junction
current :
Low reverse current
voltage :
High reverse voltage
recovery time :
Ultra fast reverse recovery time
Description

RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier

RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD RectifierFEATURES

• Low profile package

• Ideal for automated placement

• Glass passivated junction

• Low reverse current

• High reverse voltage

• Ultra fast reverse recovery time

• Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C

• Solder dip 260 °C, 40 s

• Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC

TYPICAL APPLICATIONS

For use in high frequency rectification and freewheeling application in switching mode converters and inverters for consumer, computer, automotive and telecommunication.

MECHANICAL DATA

Case: DO-214AC (SMA) Epoxy meets UL 94V-0 flammability rating

Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD22-B102 E3 suffix for consumer grade, meets JESD 201 class 1A whisker test, HE3 suffix for high reliability grade (AEC Q101 qualified), meets JESD 201 class 2 whisker test

Polarity: Color band denotes the cathode end

MAXIMUM RATINGS (TA = 25 °C unless otherwise noted)

PARAMETER SYMBOL BYG23M UNIT
Device marking code BYG23M
Maximum repetitive peak reverse voltage VRRM 1000 V
Average forward current TA = 65 °C IF(AV) 1.5 A

Peak forward surge current 10 ms single half sine-wave

superimposed on rated load

 IFSM 30 A

Pulse energy in avalanche mode, non repetitive

(inductive load switch off) I(BR)R = 1 A, TJ = 25 °C

 ER 20 mJ
Operating junction and storage temperature range TJ, TSTG - 55 to + 150 C

RATINGS AND CHARACTERISTICS CURVES (TA = 25 °C unless otherwise noted)

RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier

PACKAGE OUTLINE DIMENSIONS in inches (millimeters)

RF Integrated Circuit Chip BYG23M-E3-TR Ultrafast Avalanche SMD Rectifier
