UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
UV Coated Melamine Backup Board
Specifications
Brand Name :
DXE
Model Number :
25-HRW/20-HRW/15-HRW/25-URW
Certification :
ISO90001
Place of Origin :
China
MOQ :
1260 Sheets
Price :
USD 2.70-3.00/Sheet
Payment Terms :
L/C, T/T
Supply Ability :
100,000 Sheets/Month
Delivery Time :
15 Days
Packaging Details :
315 sheets/Pallet 16 Pallets/20'GP
Application :
For High-class and Multi-Layer PCB board Drilling
Coating :
UV Coated
Coating Sides :
Double
Size(inch) :
37"x49"/41"x49"/43"x49"
Type :
25-HRW/20-HRW/15-HRW/25-URW
Surface Hardness(Shore-D) :
75±5/75±5/75±5/80±5
Thinkness(mm) :
2.5/2.1/1.6/2.5
Thinkness Tolerance(mm) :
±0.15
Description

Eco-Friendly UV Coated Melamine Backup Board For Pcb Drilling Thickness 1.6 / 2.1 / 2.5 mm

Special Features:

--UV Coating,0 Pollution

--Flat And Smooth On Surface

--Low Temperature Drill,Reduce Bit Wear And Increase Drilling Location Accuracy

--Customized Sizes Are Accepted

Shipping Terms:

EXW,FOB,CNF & CIF

Product Details:

Application
For High-class and Multi-Layer PCB board Drilling
Type
25-HRW/20-HRW/15-HRW/25-URW
Thinkness(mm)
2.5/2.1/1.6/2.5
Thinkness Tolerance(mm)
±0.15
Surface Hardness(Shore-D)
75±5/75±5/75±5/80±5
Apperance
White,Allow Some Color Shading
Size(inch)
37"x49"/41"x49"/43"x49"
Size Tolerance(mm)
±3

Type

Thickness(mm)

Thickness

Tolerance(mm)

Surface

Hardness(Shore-D)

Density

(Kg/m³)

Size

(Inch)

Size

Tolerance(mm)

Apperance

Warpage

25- HRW

2.5

±0.15

75±5

880±50

37‘’x49"

41"x49"

43"x49"

±3

White(Allow Some Color Difference)

≤0.6% Of Diagonal

20-HRW

2.1

75±5

880±50

15-HRW

1.6

75±5

880±50

25-HRW

2.5

80±5

960±50
