85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
85763-1101 Backplane Connectors CONN RCPT 120POS PCB Through Hole
Specifications
Brand Name :
AMPHENOL
Model Number :
85763-1101
Certification :
/
Place of Origin :
N/S
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
9999999+PCS
Delivery Time :
2-7 work days
Categories :
Connectors
Features :
120 Connector Receptacle, Female Sockets Through Hole Natural -
Part Status :
Obsolete
Operating Temperature Range :
-55°C ~ 125°C
Quantity per package :
12
Mounting :
Through Hole
Description

Backplane Connectors 85763-1101 CONN RCPT 120POS PCB

Categories Connectors
Features 120 Connector Receptacle, Female Sockets Through Hole Natural -
Manufacturer AMPHENOL
Series Metral®
Package Tube
Part Status Obsolete
Operating Temperature Range -55°C ~ 125°C
Mounting Through Hole
Family Name 85763
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Quantity per package 12
Fake Threat In the Open Market 95 pct.
Popularity Medium
Supply and Demand Status Limited

FEATURES

• Modular and scalable, available in 1, 2, 4 and 8 modules

• 250 contacts per 100mm connector length

• Press-fit, Solder-to-Board and Pin-in-Paste terminations

• Varying pin length enables first-mate, last-break capability

• 4 and 5 row versions available

• Dual beam contact design for receptacles

• Locating pegs option available

BENEFITS

• Flexible modular length without any loss of contact position

• High signal density

• Caters to different application requirement

• Allows sequential connection of pins for design flexibility and offers protection

• Caters to different connector sizes

• Provides electrical reliability and withstands vibration

• Enables accurate positioning of connector on PCB, holds connector in place
