800uH RM10 Electronic High Frequency Power Transformer Industrial 5v Small LED Driving
800uH RM10 High Frequency Power Transformer — Compact SMPS Solution for 5V LED Driving & Industrial Power

This RM10 high frequency power transformer is a compact, UL-recognized magnetic component designed for switch mode power supplies (SMPS). With a nominal primary inductance of 800uH, it delivers stable 5V output performance in LED drivers, industrial control power modules, chargers and small adapters — while keeping PCB footprint to a minimum thanks to the closed RM core structure.

Fully customizable: turns ratio, inductance, pin configuration, wire type and creepage distance can all be adjusted to your circuit design and safety requirements.

Key Advantages
  • UL Recognized Construction — built with UL-listed insulation system (UL File No. E332338), ready for safety-critical export markets.
  • Low EMI, Space Saving — RM series closed magnetic circuit provides excellent shielding and saves up to 40% PCB mounting area versus open E-core designs.
  • Stable 800uH Inductance — tight tolerance winding process ensures consistent output regulation batch after batch.
  • High Isolation Safety — reinforced primary-to-secondary insulation, optional TIW (Triple Insulated Wire) for reinforced isolation designs.
  • 100% Full Inspection — every unit tested for inductance, turns ratio, DCR and Hi-Pot before packing.
  • OEM / ODM Welcome — free electrical design review and sample support based on your schematic.
Technical Specifications
Item Specification
Model No. RM10 Series (customizable P/N)
Core Type / Size RM10 Ferrite Core
Core Material Mn-Zn Ferrite PC40 / PC44 (or equivalent)
Primary Inductance (Lp) 800uH ±10% @ 100kHz / 0.25V
Output Voltage 5V (other outputs customizable)
Operating Frequency 50kHz – 200kHz
Leakage Inductance ≤ 2% of Lp (secondary shorted)
Dielectric Strength 3000VAC / 60s, Primary to Secondary
Insulation Class Class B (130°C) / Class F (155°C) optional
Winding Wire Enameled Copper Wire / TIW optional
Bobbin Material PBT, UL94V-0 flame retardant
Mounting Type Vertical DIP, through hole (SMD available)
Operating Temperature -40°C ~ +130°C
Certification UL Recognized (File No. E332338), RoHS & REACH compliant
Customization Turns ratio, inductance, pin-out, lead length, marking

* Parameters above are for standard reference design. Final specification is confirmed against your approved drawing.

Applications
  • LED lighting drivers and constant current power supplies
  • 5V / 12V switching power adapters and USB chargers
  • Industrial control and instrumentation power modules
  • Flyback & forward topology SMPS
  • Home appliance control boards, smart meters, IoT devices
  • Auxiliary power supplies for communication equipment
Why Choose Us
  • Engineering-driven — in-house transformer design team, drawings and samples typically within 5–7 working days.
  • Quality system — ISO 9001 / IATF 16949 managed production, full traceability by lot.
  • Flexible MOQ — small trial orders accepted, scalable to mass production.
  • Stable supply — MTO capacity supports continuous monthly delivery schedules.
  • Responsive service — technical reply within 12 hours on working days.
Packing & Delivery
  • Packing: Anti-static tray / PE bag + inner carton + export carton, foam protected.
  • Sample Lead Time: 5–7 working days after drawing confirmation.
  • Mass Production: 15–20 working days after order confirmation.
  • Shipping: By express (DHL / FedEx / UPS), air freight or sea freight.
  • Trade Terms: EXW / FOB / CIF | Payment: T/T, L/C, Trade Assurance
FAQ
Q1: Can you make the transformer according to my own drawing?
A: Yes. Send us your schematic or specification sheet, our engineers will review it free of charge and feed back a design proposal.
Q2: What if I only need a small quantity for testing?
A: Small trial quantities are welcome. We support prototype runs before you commit to mass production.
Q3: Is the product certified?
A: The insulation system is UL recognized under file number E332338. RoHS and REACH declarations are available on request.
Q4: How do you guarantee quality?
A: 100% inspection on inductance, turns ratio, DC resistance and Hi-Pot withstand voltage before shipment, with test reports provided per lot.
Q5: What information do you need for a quotation?
A: Input/output voltage, output power, switching frequency, topology (flyback/forward), required safety standard and annual quantity.

Send us your specification today — our engineering team will reply with a design proposal and quotation within 12 hours.
