Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
Specifications
Brand Name :
SH
Model Number :
SH120-250, SH160-250, SH160-400，SH160-300
Certification :
ISO9001
Place of Origin :
shandong province, China
MOQ :
1 set
Price :
$3,000 - $15,000 / Sets
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1000sets/year
Delivery Time :
within 25 days
Packaging Details :
iron made frame wooden pallet
Condition :
New
Max. sawing width :
250mm
Max. sawing height :
120mm
Main motor :
22KW x 2sets
Feeding :
Frequency auto feeding and speed adjustable
Warranty :
12 months
Description

Double Spindle Panel Cutting Multiple Blades Rip Saw

Introduction:

1. With Inverter auto feeding

2. With carbide blade for hardwood cutting

3. With spindle center spraying water to cool blade

4. With automatic panel controlling

5. Sawing width/thickness can be done as customer needs

6. Can change big motor as customer needs

Specifications:

  • sawing width: 250mm
  • sawing height: 120mm
  • feeding : frequency auto feeding
Model SH80-300 SH120-250 SH160-250
Max. sawing width 300mm 250mm 250mm
Max. sawing thickness 80mm 120mm 160mm
Min sawing length 600mm 500mm 500mm
Motor power 15kw x2 22kw x2 30kw x2
Saw blade diameter 180mm 230mm 255mm
Machine weight 1200kg 1800kg 2000kg

Model

SH120-300

SH160-300

SH160-400
Max. sawing width 300mm 300mm 400mm
Max. sawing thickness 120mm 160mm 160mm
Min sawing length 600mm 600mm 600mm
Motor power 22kw x2 30kw x2 37kw x2
Saw blade diameter 230mm 280mm 280mm
Machine weight 2500kg 2800kg 3000kg
Feeding Variable frequency speed adjustable automatic feeding
Cooling blade Spindle center water cooling blade

Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting MachineSquare Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine

Square Log Multiple Blade Rip Saw Machine, Multirip Saw Machine Multi Rip Saw Wood Cutting Machine
