80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
Specifications
Brand Name :
SH
Model Number :
SHYM200,SHYM250, SHYM300, SHYM350,SHYM400,SHYM450
Certification :
ISO9001
Place of Origin :
Shandong Province, China
MOQ :
1 SET
Price :
USD5,000-USD1,5000/set
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
200sets/month
Delivery Time :
within 15 days
Packaging Details :
wooden pallet or iron frame packings
Name :
Multi Rip Saw for logs
Condition :
New
Blade :
Two group of blades in up/down
Feeding speed :
Frequency control
Max. sawing log diameter :
80MM-500MM
Power :
22KW*2-75KW*2
Min sawing log length :
600mm
Warranty :
12 months
Voltage :
380V,3phase,50HZ or as cusmer needs
Description

Round log multi rip saw machines, Woodworking Multiple Blades Ripsaw for hardwoods cutting

Round Log Cutting Multi Blade Rip Saw

Specifications:

Model SHYM150 SHYM200 SHYM240 SHYM260
Sawing log diameter 20-150mm 60-200mm 80-240mm 100-260mm
Min sawing log length 600mm 600mm 600mm 600mm
Main motor power 18.5KW X 2 22KW X2 30KW X2 30kw , 37kw
Feeding motor 1.5KW 1.5KW 1.5KW 1.5KW
Saw blade diameter 255mm 305mm 355mm 380mm
Weight 1570kg 1720kg 2200kgs 2300kgs
Model SHYM285 SHYM300 SHYM330 SHYM340
Sawing log diameter 130-285mm 150-300mm 150-330mm 150-340mm
Min sawing log length 600mm 600mm 600mm 600mm
Main motor power 30kw, 37kw 37KW X 2 37KW X 2 45kw, 55kw
Feeding motor 2.2KW 2.2KW 2.2KW 2.2KW
Saw blade diameter 405mm 405mm 455mm 480mm
Weight 2350kg 2450kg 2550kg 2650kg
Model SHYM360 SHYM400 SHYM430 SHYM480
Sawing log diameter 170-360mm 180-400mm 200-430mm 250-480mm
Min sawing log length 600mm 600mm 600mm 600mm
Main motor power 55KW X2 55KW X 2 75KW X 2 75KW X 2
Feeding motor 2.2KW 2.2KW 2.2KW 2.2KW
Saw blade diameter 500mm 550mm 600mm 650mm
Weight 2680kg 3500kg 3880kg 4100kg

Remarks:

Main motor power can be changed as customer needs ;

The multi ripsaw is with inverter auto feeding

Blade cooling method: shaft center spraying water to cool

80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting

80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting

Edgers Cutting Multi Blade Rip Saw

Introduction:

  • with Infrared positioning
  • for board edges cutting
  • sawing planks into small pcs
  • easy usage, no installation

Technical data :

Model HW500 HW800
Sawing thickness 15-50mm 15-50mm
Sawing width 500mm 800mm
Circular blade diameter 210mm 210mm
Electric motor 15KW 18.5KW
Blade qty 1P-6P 1P-10P
Rotation speed 3500/min 3500/min

Photos:

80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting

Heavy Duty Single Shaft Multi Blade Rip Saw / Board Edger Saw Machine

Introduction:

  • with Infrared positioning
  • for big thickness board edger cutting
  • high working efficiency, low cost ,fulfil the max. value of the wood
  • easy usage, no installation

Technical data :

Model ZHW800-70 ZHW800-80 ZHW800-100
Sawing wood height 10-70mm 10-80mm 20-100mm
Sawing wood width 800mm 800mm 800mm
Carbide blade diameter 280mm 305mm 355mm
Main motor 22KW 30KW 37KW
Blade quantity 1P-10P 1P-10P 1P-10P
Rotation speed 3500/min 3500/min 3500/min

80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting

Related Saw Machine:

Wood Slabs Cutting Circular Sawmill

Specifications:

Model

Specifications

 BPJ200 BPJ250 BPJ300
Cutting width (mm) 200 250 300
Motor power (KW) 7.5kw x 2 7.5kw x 2 7.5kw x 2
Feeding Frequency variable auto feeding
Circular blade diameter (mm) 300 355 405
Weight (kg) 200 220 250

We can also do bigger model as customer needs .

Photos :

80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting

80mm-500mm Multi Blade Rip Saw Machine For Hardwoods Cutting
