Specifications
Place of Origin :
Shandong Province, China
Brand Name :
SH
Certification :
ISO9001,CE
Model Number :
MJ700,MJ1000,MJ1300,MJ1600
MOQ :
1 SET
Price :
US $4,500 - 12,200 / Set
Packaging Details :
iron frame pallet or film wrapped packings
Delivery Time :
within 15 days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1000sets/year
Condition :
New
Type :
Horizontal band saw
Use :
Woodworking
Usage :
Wood / Log Cutting
Voltage :
380V/3phase/50HZ or as customer needs
Power(W) :
7.5kw-30kw
Weight :
600-1500KG
Warranty :
12 month
Application :
Cutting soft/hard Log
Engine :
Electric / Diesel / Petrol Engine
Control :
Manual / Computer Control
Other :
We can customize machine according to customer needs
Description

The portable horizontal band sawmill is designed to meet the requirements of customers in Africa ,South America and eastern europe.

  • It is simple installation,easy operation,labor saving,and high productivity.
  • This machine can be drived by either electric motor or diesel engine.
  • It is widely used by the timber processing enterprises in the virgin forests areas.

CNC Horizontal Band Sawmill

Model MJ700 MJ1000 MJ1300 MJ1600

Max. Sawing Wood Diameter

 700MM 1000MM 1300MM 1600MM

Saw Wheel Diameter

 600MM 700MM 700MM 700MM

Sawing Wood Thickness

 2-250MM 2-300MM 2-300MM 2-300MM

Sawing Wood Length MM

 1300-4500 1300-4500 1300-4500 1300-4500

Main Motor Power

 15KW 18.5KW 22KW 30KW

Lifting Motor Power

 1.5KW 1.5KW 1.5KW 1.5KW
Walking motor power 2.2kw 2.2kw 2.2kw 2.2kw

Total Weight (KG)

 1100 1100 1300 1500

Images:

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

Optional - Pneumatic log clamping

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

Optional - Board returning hook

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

Optional - Mobile usage + hydraulic log loading arm

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

PORTABLE ELECTRIC HORIZONTAL BAND SAWMILL -electrical

Technical Parameter

 MJ700E MJ1000E MJ1300E MJ1600E

Max. Sawing Wood Diameter

 700MM 1000MM 1300MM 1600MM

Saw Wheel Diameter

 600MM 700MM 700MM 700MM

Sawing Wood Thickness

 2-250MM 2-300MM 2-300MM 2-300MM

Sawing Wood Length MM

 1300-4500 1300-4500 1300-4500 1300-4500

Main Motor Power

 15KW 18.5KW 22KW 30KW

Lifting Motor Power

 1.5KW 1.5KW 1.5KW 1.5KW

Total Weight (KG)

 600 1100 1300 1500

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with railsChina forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

Related Products

Wood Board Edger Saw

Technical data:

Model EG600A EG800 EG1000
Max. Processing width 600mm 800mm 1000mm
Min. Processing width 50mm 50mm 50mm
Max. Processing height 70mm 70mm 70mm
Blade 2*350mm 2*350mm 2*350mm
Feeding method Automatic feeding conveyor
Feed Rate 20-25m/ minute, speed adjustable
Electric motor power 7.5KW x 2sets 7.5KW x 2sets 7.5KW x 2sets
Machine weight 1000KG 1600KGS 1800KGS

Customize:

Working electric voltage, bigger motor power

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

China forest portable sawmill horizontal diesel band saw /mobile bandsaw with rails

Item Auxiliary Equipment
1 MR1111 Automatic Band Saw Blade Sharpener
2 Sand Wheel For MR1111
3 UN65 Flash Seal Welding Machine
4 MR417 Roll Machine
5 Dual Tooth Setter
6 USA Lenox Bi-Metal Blade For MJ700 5500*54*1.07mm
USA Lenox Bi-Metal Blade For MJ1000 6100*54*1.07mm
USA Lenox Bi-Metal Blade For MJ1300 6600*54*1.07mm
USA Lenox Bi-Metal Blade For MJ1600 7100*54*1.07mm
7 Wood Cant Hook 48” Handle
