Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
Specifications
Place of Origin :
shandong province, China
Brand Name :
SH
Certification :
ISO9001
Model Number :
MJH700E, MJH1000E
MOQ :
1 SET
Price :
US $15,900 - 24,700 / Set
Packaging Details :
Container loading
Delivery Time :
within 25 days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
500Sets /year
Name :
log cutting band saw portable sawmill
Type :
Band Saw
Use :
Woodworking
Power(W) :
22 kw or 30 kw
Warranty :
12 month
Cut max. wood diameter :
700mm or 1000mm
Saw wheel diameter :
700mm
Saw wheel width :
75mm
Sawing wood max. length :
4meters or as customer needs
Operation :
Automatic
Description

Hydraulic Band Sawmill Machine With Electric Motor

The max. cutting wood diameter can be customized as your requests

Model
 MJH1000E MJH700E
Max Sawing Wood Diameter
 1000mm 700mm
Saw Wheel Diameter
 700mm 700mm
Max Sawing Wood Thickness
 300mm 300mm
Standard Sawing Wood Length
 4000mm 4000mm
Electric Motor Power
 30kw 22kw
Up/Down Electric Motor
 1.5kw 1.5kw
Forward/backward Electric Motor
 2.2kw 2.2kw
Saw Blade Width
 27mm-75mm 27mm-75mm
Blade Tension
 Hydraulic Hydraulic
Machine Length
 5800mm 5800mm
Weight
 2500kg 2300kg

Standard Configuration
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Touch Screen Accuset Setworks

Automatically moves head for each cut and head walking speed is Frequency variable

 Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Hydraulic Clamp *1

Secure and stabilize the log
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Hydraulic Wood Clamp*4

Secure and stabilize the log

 Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Hydraulic vertical side supports *4

Secure and stabilize the log
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Hydraulic Log Loading

Arm *1

 Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill Board automatic return hook
Optional parts:
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Mobile Wheels,

8 Adjustable Up/down legs

 Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Hydraulic bi-directional Chain log turner*2

For max. log control
Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill Hydraulic plank roller axle x1 Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill Extend The Rail Length

Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Related Saw Machine

Heavy Duty Hydraulic Automatic Wood Cutting Horizontal Band Sawmill

  • Combined with Hydraulic automation technology, the heavy duty hydraulic horizontal band sawmill realizes all digital intelligent control .
  • Chinese and English operating systems, automatic rotation, sawing and cutting of large diameter wood, simple operation of equipment, precise cutting thickness, improves wood usage rate .

Technical Data:

Model
MJH1200E
MJH1500E
Max Sawing Wood Diameter
1200mm
1500mm
Saw Wheel Diameter
1000mm
1070mm
Max Sawing Wood Thickness
400mm
400mm
Standard Sawing Wood Length
4500mm
4500mm
Electric Motor Power
37kw
45kw
Up/Down Electric Motor
2.2kw
2.2kw
Forward/Backward Electric Motor
3kw
3kw
Band Saw Blade Width
125-150mm
125-150mm
Band Saw Blade Tension
Electric
Machine Length
7000mm
7000mm
Weight
7000kg
8500kg

Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill

Quality Automatic Wood Cutting Hydraulic Horizontal Bandsaw SawmillQuality Automatic Wood Cutting Hydraulic Horizontal Bandsaw Sawmill
