Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
Specifications
Place of Origin :
shandong province
Brand Name :
SH
Certification :
ISO
Model Number :
MJ3212-Z5000,MJ3212-Z3000,MJ3210-Z5000,MJ3310-Z3000
MOQ :
1 SET
Price :
US $5,000 - 50,000 / Set
Packaging Details :
container loading
Delivery Time :
within 15 days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1500sets/year
Condition :
New
Usage :
Woodworking
Max. sawing log diameter :
1500mm
saw wheel diameter :
1250mm
Bandsaw blade width :
150mm
Carriage walking forward/back :
Frequency automatic
Wood grasp :
Electric
Size setting :
PLC touching screen
Description

Descriptions of vertical band saw wood machine

Vertical Band Sawmill With CNC Log Carriage

1. This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.

2. Applications:Processing large and middle logs and square logs together with large-or middle-size wood band saws.
3. Features:Automatic micro-computer control,feeding,and automatic dimensioning;high efficiency and low labor intensity;high precision,and easy operation.

MJ3212B Vertical Band Sawmill with CNC Log Carriage

Specifications :

Technical data MJ3212B-ZD3000 MJ3212B-ZD5000
Saw wheel diameter 1250mm 1250mm
Maximum sawing log diameter 1500mm 1500mm
Maximum sawing log length 4meters 6meters
Main motor 45KW 45KW
Saw blade L*W*T 9200x150x1.25mm 9200x150x1.25mm
Carriage clip stake quantity 3sets 4sets
Wood grasp mode Electric Electric
Carriage walking/advance Frequency converter Frequency converter
Setting sawn size PLC touching screen PLC touching screen
Carriage length 3meters 5meters
Rail length 10meters 18meters
Weight 11000kgs 12000kgs

Photos :

Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage

Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage

Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage

MJ3212 Vertical Band Sawmill With CNC Log Carriage

1.Max. sawing log diameter : 1200m

2.Carriage walking : Inverter

Specification:

Technical data MJ3212-ZD3000 MJ3212-ZD5000
Saw wheel diameter 1250mm 1250mm
Maximum sawing log diameter 1200mm 1200mm
Maximum sawing log length 4meters 6meters
Main motor 37KW 37KW
Saw blade L*W*T 8600x150x1.25mm 8600x150x1.25mm
Carriage clip stake quantity 3sets 4sets
Wood grasp mode Electric Electric
Carriage walking/advance Frequency converter Frequency converter
Setting sawn size PLC touching screen PLC touching screen
Carriage length 3meters 5meters
Rail length 10meters 18meters
Weight 7500kgs 8000kgs

Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage

Wood sawmill band sawing machine, Vertical Band Saw Sawmill With Log Carriage
