Turbine Housing Gasket Turbo Seal C Ring
Turbine Housing Gasket Turbo Seal C Ring
Turbine Housing Gasket Turbo Seal C Ring
Turbine Housing Gasket Turbo Seal C Ring
Specifications
Brand Name :
TONGLINT
Model Number :
Various
Certification :
TS16949 / SGS
Place of Origin :
Jiangsu ,China
MOQ :
10 pcs
Payment Terms :
Western Union, T/T
Supply Ability :
10000 per month
Delivery Time :
1-5 working days
Description :
Seal C Ring
Packaging Details :
Neutral Packing
Description

Turbine Housing Gasket Turbo Seal C Ring

Tonglint Code Model D
(mm)		 d MIN
(mm)		 C Φ
(mm)
T-CR-001 HE561 Ø170.55 Ø166.64 Ø2.36
T-CR-002 HE551 Ø167.55 Ø163.64 Ø2.36
T-CR-003 HE431 Ø161.01 Ø157.166 Ø2.36
T-CR-004 Ø136.83 Ø132.62 Ø2.67
T-CR-005 451642-150.37-1 Ø150.37 Ø144.81 Ø3.27
T-CR-006 451642-172.03-7 Ø172.03 Ø166.95 Ø3.27
T-CR-007 451642-168.03-10 Ø168.03 Ø162.95 Ø3.27
T-CR-008 451642-164.03-6/2/3 Ø164.03 Ø158.95 Ø3.27
T-CR-009 451642-160.99-4 Ø160.99 Ø155.45 Ø3.18
T-CR-010 451642-144.65-5 Ø144.65 Ø138.99 Ø3.18
T-CR-011 451642-95.61-8 Ø95.61 Ø90.53 Ø3.18
T-CR-012 Ø107.605 Ø104.57 Ø2.38
T-CR-013 Ø167.4 Ø164.21 Ø2.38
T-CR-014 2531 Ø165.18 Ø162.48 Ø1.596

Turbine Housing Gasket Turbo Seal C RingTurbine Housing Gasket Turbo Seal C Ring

Turbine Housing Gasket Turbo Seal C RingTurbine Housing Gasket Turbo Seal C Ring
