Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material
Specifications
Brand Name :
Shunda
Model Number :
SMD-90
Certification :
CE
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
L/C, T/T
Delivery Time :
20-35 Working Days
Packaging Details :
Wooden Pallet for paper cup machine
Supply Ability :
20 sets/month
Speed :
100-120Pcs/Min
Material :
135-450Gsm Single and double PE Coated Paper
Configuration :
ultrasonic Heating
Cup Size :
2-46Oz (Mould Replacement Is Available)
Weight :
3400KG
Output :
380v , 50HZ
Description

Automatic Paper Cup Machine with 160Pcs/Min& 135-450GSM Material

Description

ZBJ-12A type paper cup forming machine is an automatic paper cup machine with multi-running positions. The machine runs a whole procedure of paper feeding , guling , oiling , bottom punching , heating , rolling , rounding and tripping . It uses the microcomputer control frequency changer , and it may automatically transform the speed.

Specification

Model SMD-90 　 　 　
Capacity pcs/min 100-120 90-110 80-100
Size Range mm(max) Top diameter:90
Bottom Diameter:80
Height:140		 Top diameter:110
Bottom Diameter:80
Height:170		 Top diameter:125
Bottom Diameter:100
Height:170
Suitable Paper Thickness gsm 135-450 　 　
Sealing Method 　 Ultrasonic and hot air system 　 　
Running Power KW 10 11 12
Air compressor 　 0.4m²/Min. 0.5MPa 0.5m²/Min. 0.5MPa 0.6m²/Min. 0.5MPa
Net weight Kgs 3400 3500 3600
Machine dimension mm 2500*1800*1700 2600*1800*1800 2700*1800*1800
Collector Dimension mm 900*900*1760 1000*900*1860 1100*900*1860

Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material


Whole process

Shunda could supply you the whole production line from printing, die-cutting, cup forming and packaging.

Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material

Cup sample

Automatic Paper Cup Machine with 160 Pcs/Min& 135-450GSM Material

Machine video

https://www.youtube.com/watch?v=3vboPdSjjAo

QUANTITY GUARANTEE:

The Seller guarantee the machines are new 100% and the guarantee period shall be given 3 years which starts from the date of the machine’s arrival. During this period, the Seller shall provide free spare parts that caused by the machine’s quality.

Contact ----- Ms Julia

Mobile(Whatsapp): +86-15157479016

Email: shunda3@chinapapercupmachine.com

Address: No.1 Jeans Road, Warp Knitting Industry Park,Haining city, Zhejiang Province.
