Specifications
Model NO. :
GD-IP67
Contact Resistance :
Below 5m
Rated Voltage :
1000V(TUV),600V(UL)
Rated Current :
25A/30A/45A/80A Optioanl
Warranty :
2 Year
Model No. :
PV Mc004-3t1
Shape :
Round
Transport Package :
Standard Export Carton
Specification :
2.5/4/6 14/12/10AWG
Trademark :
Golden Electric or Customize
Origin :
China
HS Code :
8537209000
Supply Ability :
5000/Month
Application :
Power
Certification :
ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
Terminal Material :
Copper
Interface Type :
DC/DC
Housing Material :
PPO
Flame Class :
UL94V-0
Samples :
US$ 0.8/Piece 1 Piece(Min.Order) | Request Sa
Customization :
Available | Customized Request
Place of Origin :
China
Brand Name :
Golden Electric /OEM
MOQ :
1
Packaging Details :
Carton/Pallet
Delivery Time :
Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Payment Terms :
LC, T/T, PayPal, Western Union
Description

Product Description

MC-4 Solar Panel Cable Connectors with Assembly Tool,10 Pairs Copper Solar Wire Adapter Male/Female Waterproof Connector for Connecting Solar Panels 1000V 30A

Features


1.Load Capability with big current and high voltage
2.Lower contact resistance
3.Desugn of waterproof and dustproof
4.Excellent performances of high-low temperature,fireproof ,anti-ultraviolet

Product Parameters

Type PV-004-D
Rated Voltage 1000V DC/1500V DC
Contact resistance <1mΩ

Rated current:

30A/50A
Temperature range -40ºC ~ +85ºC

Contact material

 Copper,tin plated

Insulation Voltage

 6000V
Fire-proof level UL94-V0

Details display

The head
Similar to the male MC4 connector, high-strength waterproof ring, waterproof level reaches IP67
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4
Solid in the middle and can be engraved with standard voltage and current ratings


Similar to MC4 female connector, for safe docking
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4

Drawings

DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4

Application field

Applied to solar amorphous silicon module power generation projects, household roofs, greenhouse farming, fish farm farming, traffic lights, parking lot charging stations, commercial buildings, deep water well drinking/irrigation, etc.
DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4

Other Hot-Selling Models

DC/DC Interface Type PV Mc004-3t1 PV Solar Connectors 1000V/30A PV004-D Match with Mc4The Delivery time and shipping of MC4 solar cable connector
Deilivery time:
1-7 days after confirming order
Shipping:
1. Shipment port:GUANGZHOU
2. By Air or by Sea for batch goods,Airport/ Port receiving;
3. Customers specifying freight forwarders
