2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
Specifications
Brand Name :
PTE
Model Number :
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
wooden case
Packaging Details :
within 10 days after the confirmed order
Usage :
Universal Testing Machine
standards :
ASTM, DIN, BS, JIS, GB, etc.
test material :
metal,plastic,rubber,spring, all kinds of rope material
fields :
metallurgy, machinery, building engineering,industry,lab,factory
Load accuracy :
≤±1%
Description

2017 HOT RTH Computerized Electronic school testing equipment(creep tester)
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)

Specifications

Creep testing machine
1.Routine creep,stress-rupture,tensile test
2.Digital display
3.High accuracy
4.laboratory equipment

HOT Computerized Electronic Laboratory Equipment for creep testing machine

Application

RTH series is a kind of full electronic creep rupture testing machine to perform routine creep and stress-rupture test., and also can carry on stress relaxation test, high-temperature tensile test in short time, cycle load test (load spectrum test), low cycling test etc.

Test Load

  • Max. Load: 30kN, 50kN, 100kN, 200kN
  • Effective measuring range: 1%-100%FS;
  • Test load accuracy: ≤1%;
  • Resolution: 1/60000

High temperature furnace & Temperature-controller

  • Working Temp. range: 400°C~1200°C
  • Length of effective soaking zone: 150mm
  • Furnace pipe & electric furnace size:
  • Furnace pipe: φ90mm (Inner Dia.)×400mm (L),
  • Furnace: φ300mm (outer Dia,)×420mm (L);
  • Furnace life: ≥3000hours (Constant working time less than 1000°C)
  • Furnace Temperature accuracy (°C):
Test Temperature Temperature fluctuation Temperature gradient
less than or equal to 600 ±2 2
More than 600~900 ±3 3
More than 900~1200 ±4 4
  1. Measure & Control temperature meter: digital display, sensitivity: 0.1°C;
  2. Measure & Control temperature meter: digital display, sensitivity: 0.1°C;
  3. Auto compensation error of cold end:≤0.5°C;
  4. To be matched freely with thermocouple.
  5. Moving speed of lower grip holder
  6. Speed range: 0.005~50mm/min;
  7. Error: ±0.5%
  8. Timing error: ±0.2%



2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
Three Star Service :
*First Star---Pre-service
24 Hours online service for your consult
Help choose right model,and a series of service,person,advise.
*Second Star---Middle Service
--Give you best offer
--Provide discount for many sets order
--Do customer's request
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
. *Third Star---After serivce
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Provide newest software vision when update
--Remote control technical consult
--Free installation DVD
--Maintenance plan
2012 HOT RTH Computerized Electronic school testing equipment(creep tester)
