Specifications
Brand Name :
ZTZG
Model Number :
ERW89
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets/year
Delivery Time :
90 days
Packaging Details :
All mechanical equipment is nude packing and electrical parts are packed in wooden cases
Product Name :
ERW20 High Frequency Straight Welded Pipe Production Line Square Tube Mill
Shape :
Square
Raw Material :
Carbon Steel Coil
Length :
6-12 m
Thickness :
1.5mm-4.5mm
Voltage :
220/380/415/420/440V
Power(w) :
150 kw
Worker :
6-8 Workers
After-sales service provided :
Engineers available to service machinery overseas,Online support
Application :
Construction,Furniture
Useful life :
30 years for Steel Tube Mill
Service :
Free technical consultation
Description

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

ERW89 high frequency longitudinal welded pipe production line / pipe making machine / tube mill is designed to produce welded pipes of 42mm-89mm in OD and 1.5mm-4.5mm in wall thickness, as well as corresponding square and rectangular pipe.

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

Advantage:

Low wastage, low unit wastage and low production cost.
High yielding, the machine works stably at a high speed, which improves the yielding of products.

High production efficiency, line speed can be up to 120m/min.
High accuracy, diameter error is only 0.5/100 of the pipe OD.

Carbon Steel Tube Production Line Square ERW Pipe Mill Making Machine

Basic Technical Information of Welded Pipe Production Line

Product&yield

Round Pipe

42mm-89mm Thickness:1.5mm-4.5mm
Square & rectangle tube

35mm×35mm -70mm×70mm Thickness:1.5mm-3.5mm

Length

6m-12m Length Tolerance: ±3mm

Production Speed

20-110 m/min

Production capacity

22,000ton/year

Consumption

Mill installed capacity

150 kw

Line Area

72m(length) ×5.5m (width)

worker

6-8 workers

Raw Material

Carbon Steel coil

GB/T 700: Q235B(ASTM: GR·D(σs 230) / JIS: SS400)

Width

130mm-280mm Thickness: 1.5mm-4.5mm

Coil ID

550-610mm

Coil OD

Max 1600mm

Coil Weight

4.0t

Technical flow

Scrolling up→ Uncoiling → Shear and Welding→ Spiral accumulator→ Forming → H.F. induction welding→ External burr removing→ Cooling → Sizing→ Flying saw → Run out table →Inspecting→ Packing→ Warehouse

We can also design square tube machine depends on customer’s requirement.
