Specifications
Brand Name :
ZTZG
Model Number :
ERW114
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets/year
Delivery Time :
90 days
Packaging Details :
All mechanical equipment is nude packing and electrical parts are packed in wooden cases
Product Name :
ERW API Steel Tube Making Machine No Need Change Rollers ZTF Pipe Mill
Pipe shape :
Square,Rectangular
Length :
6m-12m
Thickness :
0.5mm-1.5mm
Voltage :
220/380/415/420/440V
Power(w) :
160 kw
Raw Material :
Carbon Steel Coil
Worker :
6-8 Workers
After-sales service provided :
Online support
Application :
Energy Supply Pipe,Construction,Furniture
Useful life :
20 years for Steel Tube Mill
Service :
Free technical consultation
Description

ERW API Steel Tube Making Machine No Need Change Rollers ZTF Pipe Mill

ERW114 high frequency longitudinal welded pipe production line / pipe making machine / tube mill is designed to produce welded pipes of 48mm-114mm in OD and 1.5mm-4.5mm in wall thickness, as well as corresponding square and rectangular tube.

ERW API Steel Tube Making Machine No Need Change Rollers ZTF Pipe Mill

ERW API Steel Tube Making Machine No Need Change Rollers ZTF Pipe Mill

Advantage:

Low wastage, low unit wastage and low production cost.
High yielding, the machine works stably at a high speed, which improves the yielding of products.

High production efficiency, line speed can be up to 120m/min.
High accuracy, diameter error is only 0.5/100 of the pipe OD.

Products: architectural structure tubes, low-pressure liquid tubes, coal transmission belt tubes, drive shaft tubes, guardrail tubes, tower footing tubes, automobile beam steel tube and other products.

ERW API Steel Tube Making Machine No Need Change Rollers ZTF Pipe Mill

Basic Technical Information of Welded Pipe Production Line

Product&yield

Round Pipe

48mm-114mm Thickness:1.5mm-4.5mm
Square & rectangle tube

40mm×40mm -90mm×90mm Thickness:1.5mm-4.0mm

Length

6m-12m Length Tolerance: ±3mm

Production Speed

20-65 m/min

Production capacity

30,000ton/year

Consumption

Mill installed capacity

160 kw

Line Area

78m(length) ×6m (width)

worker

6-8 workers

Raw Material

Carbon Steel coil

GB/T 700: Q235B(ASTM: GR·D(σs 230) / JIS: SS400)

Width

150mm-360mm Thickness: 1.5mm-4.5mm

Coil ID

550-610mm

Coil OD

Max 1600mm

Coil Weight

4.0t

Technical flow

Scrolling up→ Uncoiling → Shear and Welding→ Spiral accumulator→ Forming → H.F. induction welding→ External burr removing→ Cooling → Sizing→ Flying saw → Run out table →Inspecting→ Packing→ Warehouse

ZTF forming process:Save alt least 60% roller cost with electric control adjustment

We can also design square tube machine depends on customer’s requirement.
