90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
Specifications
Brand Name :
Lemon
Model Number :
LM-ED90
Certification :
CE
Place of Origin :
China
MOQ :
50pcs
Price :
5USD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 Pieces/ month
Delivery Time :
7-15 days
Packaging Details :
Carton Packing
Material :
94V0 Plastic
Emergency duration :
90 minutes
Battery :
500 mAh Ni-cd
Watt :
2W LED
Description

Recessed Mounted 2W LED Emergency Light

Non-maintained type Model: LM-ED90

90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire
90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire

I. Product Feature

  1. This LED Automatic Emergency lamp is an excellence It is a fashionable and lightweight design.
  2. Lamp body made from PC/ABS special plastic.
  3. Perfect electronic circuit design base on advanced intelligent IC, has many automatic functions. automatice emergency lighting turn, automatic monthly self-inspect, automatic yearly self-inspect, over-charge protection and over-discharge protection.
  4. Ni-cd battery built in. the lamp, very easy install.

90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire

II. Model and basic parameter

Model No. Dimensions Input

Power

Consumption

 Emergency Duration Battery
LM-ED90 120X120X42mm

220-240V~

50/60Hz

 MAX 2W 90minutes

600mAh

Ni-cd

III. LED Indicators and Test button Functions

  1. Indicators
On Off
Green Main Power Available Main Power Not Available
Red charging charging completed
Yellow Light Problem Light No Problem

2. Test Button

Press one time Press twice in succession
  1. Main power available, the lamp light up with battery.
  2. In self-test state, press one time, the lamp will exit self-test.
  1. In Emergency working, press twice the test button, the lamp will be turn off.
  2. Main power available, press twice, the lamp will turn to self-test.

90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire

90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire

90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire

90 Minutes Recessed Mounted Fire Exit LED Emergency Luminaire

IV. Caution

1. Before installation or maitenance, must ensure the AC power is off.

2. emergency lamp installation and maintenance needs the competent person operating.

3. The lamp can not be used outdoors ,humid places or high temper
4. Battery up to four years in the lamp needs to be replacedature area.

5.The battery of self-contained emergency luminaire is not a user serviceable item and shall only be reaplace by the competent person

6.when the yellow indicator light up, press the test button one time, if the yellow indicator still lighting, please ask the professionals help, don’t repair yourself.
