European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
Specifications
Model NO. :
European version of rough grinding
Condition :
New
Warranty :
1year
After-sales Service :
1year
After Sale Service :
Free Initial Installation at Home and Abroad
Spare Parts :
for Whole Using Life
Test&Installation :
Professional Engineer Assigned
Export Markets :
Global
Transport Package :
Standard Container
Specification :
Enterprise Standard
Trademark :
Dingbo Machinery
Origin :
Shanghai, China
HS Code :
8474209000
Supply Ability :
100sets/Month
Type :
Ball Mill
Motor Type :
AC Motor
Motor Power :
5.5KW
Rotationl Speed :
20-22r/min
Application :
Construction
Materials :
Lead
Customization :
Available | Customized Request
Place of Origin :
China
Certification :
ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, QC 080000
MOQ :
1
Packaging Details :
Normal Packing Ls in Wooden Cases
Delivery Time :
Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Payment Terms :
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Description
European Version of Rough Grinding Limestone Coarse Powder Mill with Lead MaterialsEuropean Version of Rough Grinding Limestone Coarse Powder Mill with Lead MaterialsEuropean Version of Rough Grinding Limestone Coarse Powder Mill with Lead MaterialsEuropean Version of Rough Grinding Limestone Coarse Powder Mill with Lead MaterialsEuropean Version of Rough Grinding Limestone Coarse Powder Mill with Lead MaterialsEuropean Version of Rough Grinding Limestone Coarse Powder Mill with Lead MaterialsEuropean Version of Rough Grinding Limestone Coarse Powder Mill with Lead Materials
Shanghai Dingbo company can provide you various kinds of Grinding Mill, such as the Rough Grinding Mill, Grinding Mill, . Especially our European Version of Rough Grinding Mill is the unique equipment in China. We can recommend you the suitable model of grinding mill.
Product description:
European version of rough grinding mill is widely used in metallurgy, mining, chemical, cement, coal, dry stone, construction, sand, refractories and ceramic industrial and mining enterprises, engaged in breaking and crushing the material in the operation. It is mainly suitable for crushing compression strength not higher than 320 MPa of various soft and hard ore.
Product features:
1. Different kinds of crusher to choose, hammer crusher, jaw crusher, impact crusher, cone crusher, etc.
2. High capcity, high crushing ratio, 3-300 t/h.
3. Uniform particle size, simple structure
4. Low investment, easy operation and maintenance.
5. applied to industries of metallurgy, mining, chemistry, cement, construction, refractory materials, ceramics
6. can crush hard and soft ores into medium or small size, such as barite, limestone, gypsum, terrazzo, coal, slag, and up to 100 different kinds.
Structure and working principle:
The european version is mainly by coarse grinding casting, rotor, bearing the hammer and the bars and other components. Upper and lower case in two parts, welded together by a steel plate after cutting, the remaining parts bolted into one. Set with high manganese steel liner inside the case, to facilitate replacement of wom; Its array of rules installed on the spindle distribution of the hammer, hammer and rotary table and through the rotor shaft formed. Host through the motor, v-belt driven spindle, so that the rotor rotates, hammer by the centrifugal force generated by rotation around the stretch to, bulk materials from the feed inlet into the crushing chamber, the high-speed movement of the hammer will be crushed broken by passing the material under.
Model PC4008-75 PC4012-90 PC4015-132
Rotor diameter /mm 750 900 1150
Rotor length/ mm 800 1200 1500
Rotor speed? r/min 800-1000 800-1000 550-800
Feed head size/mm 320× 930 400× 1200 500× 1500
Max feed size/mm < 50 < 50 < 100
Fineness/mm 0-3 0-3 0-8
Processing? t/h 10-30 30-60 60-100
Motor Power/Kw 55-75 75-90 110-132
The number of hammer 18 32 32
Dimensions L*W*H/mm 2310*1665*1610 2840*2100*2020 3720*2650*2540
