Specifications
Model NO. :
PY SERIES
Drive :
Electric
Crushing Style :
Extruding & Milling
Compressive Strength (For Crushing) :
>300MPA
Crushing Degree :
Fine Grinding Machine
Finished Surface :
Outer Surface Process
Certification :
ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, QC 080000
Condition :
New
Color :
as Clients Require
Installation :
Free Initial Installation
After Sales Service :
Service for One Year
Size of Unit :
Small, Midium, Large, Xl
Usage :
Industrial
Product Type :
Paint
Transport Package :
Standard Container or Negotiable
Specification :
International
Trademark :
Dingbo Machinery
Origin :
Shanghai China
HS Code :
84742090
Supply Ability :
100sets/Month
Package Size :
265.50cm * 220.60cm * 311.00cm
Package Gross Weight :
11000.000kg
Lead Time :
30 days (1 - 1 Pieces) To be negotiated ( > 1 Pieces)
Warranty :
1years
Type :
Crusher
Application :
Machinery & Hardware, Chemical, Construction, Mineral Industry, Stone Industry, Cone Crusher
Customization :
Available | Customized Request
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Place of Origin :
China
MOQ :
1
Packaging Details :
Normal Packing Ls in Wooden Cases
Delivery Time :
Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Payment Terms :
LC, T/T, D/P, PayPal, Western Union, Small-amount payment,
Description

Spring Cone crusher have features of high quality, low cost and big broken ratio. This type of crushers can crush various kinds of ores and rocks of medium or above medium hardness, and cone crusher is of big ratio, high efficiency, large capacity, low cost, easy adjustment, and use economically, etc. Spring cone crushers are widely applied in metallurgical, construction, road building, chemical and phosphatic industry. Cone crushers are suitable for hard and mid-hard rocks and ores, Spring cone crushers designed with final size 2-60mm, used to crusher, Marble, Silica sand, Dolomite, Basalt, Quartz, Feldspar, Limestone, Granite, Slag. The type of crushing chamber depends upon size of feeding and fineness of crushed product. The standard type (PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing , and the short head type is applied to fine crushing.
After Sales Service for One Year Mantle Concave Granite Ore Cone Crusher
After Sales Service for One Year Mantle Concave Granite Ore Cone Crusher
After Sales Service for One Year Mantle Concave Granite Ore Cone Crusher
After Sales Service for One Year Mantle Concave Granite Ore Cone Crusher
After Sales Service for One Year Mantle Concave Granite Ore Cone Crusher
After Sales Service for One Year Mantle Concave Granite Ore Cone Crusher



Main features and benefits

1. High quality and productivity.
2. Less machine stop time.
3. Easy maintenance and low cost.
4. Unique crushing ability in primary, secondary and tertiary crushing.
Product Parameters
Model Moving Cone Diameter
(mm)		 Feeding
Opening Size
(mm)		 Discharging Opening Size
(mm)		 Max Feeding Size
(mm)		 Capacity
(t/h)		 Eccentric
Rotation
Speed
(r/min)		 Electric Motor
Power
(kw)		 Weight
(t)		 Overall
Dimension
(mm)
PYB600
600		 75 12-25 65 12-25
356		 30 5 2800× 1300× 1700
PYD600 40 2-13 35 5-23 5.5
PYB900

900		 135 15-50 115 50-90 333 55 11.2 3050× 1640× 2350
PYZ900 70 5-20 60 20-65 11.2
PYD900 50 3-13 50 15-50 11.3
PYB1200


1200		 170 20-50 145 110-168 300 110 24.7 4152× 2300× 2980
PYZ1200 115 8-25 100 42-135 25
PYD1200 60 3-15 50 18-105 25.6
PYB1750

1750		 250 25-50 215 280-480 245 160 50.5 6020× 2948× 4192
PYZ1750 215 10-30 185 115-320 51
PYD1750 100 5-15 85 75-230 50.5
PYB2200


2200		 350 30-60 300 590-1000 220 260-280 84 7705× 3432× 4842
PYZ2200 275 10-30 230 200-580 85
PYD2200 130 5-15 100 120-370 85
