Product Description

The CH240QV64A is a 2.4-inch IPS TFT LCD module with 240x320 resolution, 4-Line SPI interface, and 300cd/m2 brightness, designed for compact embedded systems. Featuring full 80/80/80/80 viewing angles and a transmissive normally-black display mode, it delivers sharp contrast and consistent color from any direction. The module supports a wide operating temperature range of -20°C to +70°C, making it suitable for industrial control panels, portable instruments, and outdoor handheld devices. With a compact 10-pin SPI connection, this display enables straightforward integration with low-pin-count MCUs while maintaining crisp 240x320 pixel rendering. The IPS panel ensures sunlight readability when paired with proper enclosure design, while the normally-black mode delivers deep blacks and excellent contrast ratio for applications demanding clear data visualization in varying ambient light conditions.

Product Features

1. Compact 2.4-Inch IPS Display for Space-Constrained Embedded Systems

The small 2.4-inch form factor fits into handheld meters, portable diagnostic tools, and compact IoT control panels where every millimeter of enclosure space matters.

2. Full 80/80/80/80 Viewing Angles for Multi-Position Readability

IPS panel technology ensures consistent color and contrast from any viewing direction, enabling operators to read data clearly from off-axis positions in industrial equipment panels and monitoring stations.

3. Wide Operating Temperature Range (-20°C to +70°C)

Reliable performance across extreme environments makes this module suitable for outdoor instrumentation, cold-chain logistics trackers, and factory-floor control interfaces exposed to temperature swings.

4. Simple 4-Line SPI Interface for Low-Pin-Count MCU Integration

With just 10 pins and a straightforward SPI protocol, this display connects easily to resource-constrained microcontrollers, reducing PCB complexity and accelerating prototype development.

5. Transmissive Normally-Black Mode with 300cd/m² Brightness

The normally-black display mode delivers deep blacks and high contrast for crisp data visualization, while 300cd/m² brightness ensures legibility in indoor and shaded outdoor environments.

Product Drawing

Detailed Specifications

Customized Introduction

Chenghao delivers professional customization across TFT LCD modules, mono LCD displays, color OLED modules, and mono OLED modules. We offer:

• FPC Tailoring: Custom FPC outline, length, and pin count to match your enclosure and connector layout.
• Interface Adaptation: SPI, MCU, RGB, MIPI, LVDS, EDP, and HDMI interface options available to suit your host platform.
• Brightness Tuning: From standard 200-300 cd/m2 to high-brightness 500+ cd/m2, calibrated for indoor or sunlight-readable applications.
• Touch Integration: Capacitive touch, resistive touch, or no-touch configurations based on your product requirements.
• Anti-Glare Coating: AG surface treatment to reduce ambient reflections for outdoor and high-glare environments.
• Cover Glass Customization: Tailored glass thickness, shape, color, and silk-screen printing to match your brand and industrial design.

Contact our engineering team with your specifications for a tailored solution.

Application Cases

• Portable Measurement Instruments: The compact 2.4-inch form factor and simple 4-Line SPI interface make this display ideal for handheld multimeters, environmental sensors, and portable spectrum analyzers where space and pin count are limited.
• Industrial IoT Control Panels: Wide -20°C to +70°C operating temperature and IPS full-viewing-angle display ensure reliable operation in factory-floor control nodes, HVAC zone controllers, and smart agriculture monitoring terminals.
• Medical Handheld Devices: The transmissive normally-black mode with 300cd/m² brightness delivers clear data readout for portable glucose meters, pulse oximeters, and compact patient monitoring handhelds used in clinical settings.
• Cold-Chain Logistics Trackers: Wide-temperature capability and low-power SPI interface suit battery-operated temperature loggers and GPS tracking devices exposed to refrigerated transport environments.

FAQ

Q1: What is the interface protocol for this display?

The CH240QV64A uses a 4-Line SPI interface with 10 pins, supporting straightforward communication with low-pin-count MCUs for embedded applications.

Q2: Can this module operate in outdoor environments?

Yes. With an IPS panel, 300cd/m² brightness, and a wide -20°C to +70°C operating range, it performs reliably in outdoor instrument panels and handheld devices.

Q3: What power supply voltage does the display require?

The module operates at standard 3.3V logic levels, compatible with most ARM Cortex-M and similar low-power MCU platforms.

Q4: Is the FPC customizable for different connector layouts?

Yes. Chenghao provides custom FPC outline, pin count, and connector type options to fit your specific enclosure and PCB design requirements.

Q5: Can the brightness be adjusted via software?

Brightness can be controlled through PWM dimming on the backlight LED pins, allowing dynamic adjustment based on ambient light conditions or power-saving requirements.
