LED T8 TubeTri - proof Purifying 10W Ceiling - Mounted 6000K 100 LM / W Suspend
Quick Details
| Model No.:LTB-T810W-1 | Certificate: CE RoHS FCC |
| Item Type:T8 LED Tube | Power: 10W |
| SDCM: < 3 | Input Voltage: 85 - 265V |
| Brand name: LECCO | Lumen : 100 LM / W |
| Warranty: 2 year | Working Temp.: :- 40 - 60 ℃ |
Lamp parameters
| Type | T8 LED Tri - proof Purifying Tube 10W | |
| Optical Parameter | Color Rendering Index | > 80 Ra |
| SDCM | < 3 | |
| Color Temparature | 6400K | |
| Luminous Efficency | > 100 lm / w | |
| Light Transmittance: | > 90% | |
| Luminous Decay | < 5% at 3000hrs , < 9% at 6000hrs | |
| LED Chip Brand | Epistar | |
| Junction Temperature | 65 ℃ | |
| Chip Quantity | 50 pcs SMD 2835 , 0.2W | |
| Electronic Parameter | Power | 10W |
| Power Factor | > 0.9 | |
| Isolated Power Supply | Yes | |
| Input Voltage | 85V - 265V | |
| Current | Constact Current with IC | |
| Dirver Brand | Mosopower , Wellpower , Meanwell , Lifud | |
| Structural Parameters | Length | 300mm |
| Installation | Ceiling Mounted / Suspending | |
| Materials | PC + Aluminum | |
| IP Rating | IP 20 | |
| Thermal Tranmissivity | 160 W / ( m.K ) | |
| The Value of Permissible Voltage | < 5000V | |
| Beam Angle | 200 ° | |
| Operating Temp. | -20℃ to +40℃ | |
| Life Time | > 30 000H | |
| Energy Efficiency Grade | A | |
| Certification | CE / RoHS / FCC | |
| Lumen | > 1000 LM | |
Description
1 . Guarantee is for 2 years .
2 . The average lifetime of our LED bulb is at least 30 000h .
3 . Living up to the IEC62031 : 2008 & 62560 standard .
4 . Saving 90% electricity compared to traditional incandescent bulbs or Energy saving lamps .
5 . Can start under the condition of - 30 ℃ and low voltage .
6 . No flicker , No noise , No electromagnetic interference ( EMI ) .
8 . 50 pcs SMD 2835 Chip 0.2W ,Epistar / Bridgelux .
9 . Using pure 6063 Aluminum cover , haveing excellent heat conduction ,160 W / ( m.K ) .
10 . Using nickleplated aluminum base , very good to avoid getting rusted .
11 . For the pack , we have color box , single blister , double blister .
12 . We choose very good driver supplier like Meanwell,mosopower to have constact current output to the LED chip , which is also safe .
13 . Easy to apply , can change traditional incandescent bulbs and CFL bulbs directly , saving more energy and having longer life .
14 . All products are output strictly under ISO 9001 Quality Management System and CE satisfied .
15 . Voltage : all of our LED products supply wide range voltage input .
Trade terms
1 . Payment term : T/T , 30% deposits in advance , 70% balance before shipment .
2 . Samples can be provided for free , but the express fee need to be payed for the first time , and can be returned after placing the first order .
3 . Shipping freight are quoted under your requests .
4 . Shipping port : Shanghai / Ningbo .
5 . If not mentioned , all of our price is FOB price , and also can be CFR or CIF
Application
Widely used in home & commercial Lighting , always using together with the downlight fixtures , applying in office , Hallway , Hotel , room , shop , ect .
