Specifications
Brand Name :
CESTSEN
Model Number :
MR-50 L/X
Certification :
CNAS, CE
Place of Origin :
Shenzhen, China
MOQ :
1 pieces
Payment Terms :
T/T
Supply Ability :
300 pieces+One month
Delivery Time :
5-15 Working day
Packaging Details :
Product packaging: Aluminum box, shipping packaging:
Ray species :
α、β、γandΧ ray
Measuring range :
0.001-100mR/h、0.01-1000µSv/h、0-5000CPS
Energy response :
20KeV~3Mev
Relative inherent error :
±15%
Communication interface :
RS485, Modbus-RTU
dimension :
187*90*47mm
Description

Fixed Nuclear Radiation Monitor -MR-50L/X Monitors Alpha, Beta, Gamma And X-rays

1.Product introduction

MR-50L/X online radiation monitor, which is used to monitor the radiation level in environmental online monitoring, medical protection, solid waste treatment, customs inspection and quarantine, industrial safety production, stone radioactivity detection and other fields. It can monitor the α, β, γ and χ rays in the environment in real time and output them in RS485 mode, which is convenient for system integration. It can also be equipped with the Internet of Things cloud platform system developed by our company to facilitate users' mobile phones/computers.

The MR-50L/X on-line radiation monitor is designed in traditional unit system and international standard unit system. CPS and total count are the most direct measurement methods, and mR/h or uSV/h is calculated by [Cesium -137] conversion factor. The most direct indication of radiation level is the sound and radiation indicator lamp, and the green light flashes once every ionization time is detected.

Fixed Nuclear Radiation Monitor X Rays Alpha Beta Gamma Radiation Monitor

2.product features
1.60mm×42mm large screen display, with MAX value retention function.
2.It can be used for cumulative monitoring of radiometer values and acousto-optic secondary alarm.
3.High and low temperature resistance, good adaptability and normal operation in complex environment.
4.With RS485 output connectable data management platform.
5.The alarm threshold can be set manually, which is very convenient to operate.

3.qualification

Function/Model

MR-50X

MR-50L

MR-50A

Ray species

γand Χ ray

α,β,γandΧ ray

γandΧ ray

Detector type

Mica end window Geiger counter

Energy compensation tube

Measuring range

0.001-100mR/h,0.01-1000µSv/h,0-5000CPS

0.01-10mSv/h

Energy response

20KeV~3Mev

40KeV-1.5MeV

sensitivity

3480cpm/mR/h

1600cpm/mR/h

Relative inherent error

±15%

γ:±20% X:±30%

Unit of measurement

uSv/h, mR/h, CPS

Alarm mode

Sound, vibration

reveal

Dot matrix LCD screen 4 digits

Operating temperature

-20℃ to 60℃

Communication interface

RS485, Modbus-RTU

Power supply mode

DC 12V-24V

Electric current

25-70mA

dimension

187*90*47mm

Cloud platform communication

GPRS wireless transmission is optional

weight

约400g

约310g

Certification

radiation safety license, CNAS certification body test report, CE certification
