Ceramic Hybrid Roller Bearings High Precision 3.15gcm3
Ceramic Hybrid Roller Bearings High Precision 3.15gcm3
Ceramic Hybrid Roller Bearings High Precision 3.15gcm3
Ceramic Hybrid Roller Bearings High Precision 3.15gcm3
Specifications
Brand Name :
CSQ
Model Number :
Customized
Place of Origin :
China
MOQ :
50 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
Negotiable
Delivery Time :
Negotiable
Packaging Details :
Plastik box+carton box
Name :
Hybrid Ceramic Roller Bearing
Model :
Customized
Category :
Hybrid ceramic bearing
Precision :
Customized, according to your need
Races Material :
Steel
Roller material :
ZrO2/Si3N4/SSiC
MOQ :
50 pieces
Pacage :
Plastik box+carton box
Description
Customized Hybrid Ceramic Roller Bearing With High Precision
Description of Hybrid Ceramic Roller Bearing:
As professional ceramic bearing manufacture in China, ur company can customize hybrid ceramic roller bearings of many models too. The material of races can be chosen among stainless steel or bearing steel and assembled with ceramic rollers of zirconia, silicon nitride and silicon carbide. The hybrid ceramic roller bearing combines the nice wear resistance of steel and the excellent resistance to corrosion. Welcome your inquiry
Material properties of ceramic rollers:
Material Properties Units SSiC HIP-Si3N4 GPS-Si3N4 HIP-ZrO2
Density g/cm3 3.15-3.18 3.27-3.29 3.22-3.27 6.05-6.09
Porosity % 0 0 0 0
Fledural Strength MPa 550 830 689 900
Elastic Modulus GPa 410 310 310 200
Hardness HV5 2800 1580 1450 1300
Fracture Toughness KIC MPa.m1/2 4.6 6.1 5.7 8-11
Maximum Use Temperature ℃
(℉)		 1650
(3000)		 1000
(1830)		 1000
(1830)		 380
(716)
