Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Specifications
Brand Name :
YH
Model Number :
YH-T
Certification :
ISO
Place of Origin :
China
MOQ :
10
Price :
Negotiated
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
10000pcs per month
Delivery Time :
15-30 work days
Packaging Details :
wooden case and paper case
Volume Resistivity :
10^14 Ω·cm
Wear Resistance :
Very High
Purity :
Typically 30% to 99.9%
Maximum Use Temperature :
1700c
High Purity :
99.5% or higher
Method :
lsostatic presure
Bulk Density :
>3.63
Max Operating Temperature :
1700°C
Properties :
Electric Insulation
Melting Point :
2040°C
Transparency :
Opaque
Type :
Alumina Ceramic Parts
Alumina Content :
95%
Biocompatibility :
Yes
Precision Tolerance :
High
Description

high purity Insulating Alumina Ceramic Tube customized ceramic structure tube

Insulating Alumina Ceramic Tube: Customized Structures for High-Standard Industrial Insulation Our insulating alumina ceramic tubes are engineered for superior electrical insulation and thermal stability,
ideal for demanding applications in electronics, metallurgy, and high-temperature processing industries.
Crafted from high-purity alumina materials, these tubes deliver exceptional dielectric strength and corrosion resistance,
effectively isolating current and heat to protect critical equipment components. We offer fully customized ceramic
structure solutions—tailoring diameter, wall thickness, length, and special-shaped structures according to your exact
drawings or samples. Whether you need standard straight tubes or complex stepped, flanged, or porous structures,
our precision manufacturing ensures a perfect fit for your application scenarios.

Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom SizesWear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes

Alumina ceramic tubes of application:
1.Industrial Furnaces: Thermocouple protection tubes, furnace tubes, inspection tubes, rollers.
2.Semiconductor & Electronics:Diffusion furnace tubes, insulating sleeves, vacuum chamber components.
3.Mechanical & Wear Parts: Wear-resistant linings, guide tubes, nozzles, sealing rings.
4.Energy & Environmental: Fuel cell components, sensor protection tubes, sampling tubes.
5.Laboratory:Tube furnace tubes, laboratory glassware.
Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Industrial Ceramic Performance Specifications
Al₂O₃ Content (%) 70-75 85 95 99.7
Density (g/cm³) 3.0 3.4 3.7 3.9
Bending Strength (MPa) 85 300 364 450
Coefficient of Thermal Expansion (200℃-800℃) 6 7 7.6 8
Thermal Conductivity (W/(m·K)) 17 18 20 35
Dielectric Strength (kV/mm) 9 10 11 12
Working Temperature (Long Term Use) (℃) 1300 1400 1600 1750
Water Absorption (%) 5 <0.2 <0.25 <0.1-0.2
Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Main advantage of the Alumina ceramic tubes:
1.Maximum tolerable temperature: 1600°C–1800°C,It does not soften or deform at high temperatures,
has a low coefficient of thermal expansion, and exhibits excellent thermal shock resistance.
Alumina ceramic tubes of Feature:
1.High Temperature Resistance: Can be used for extended periods at temperatures up to 1600°C or even higher (depending on alumina purity, such as 99% alumina).
2.High Hardness and Wear Resistance: With a Mohs hardness of up to 9, second only to diamond, it effectively resists particle abrasion and erosion.
3.Excellent Electrical Insulation: Maintains good insulation performance even at high temperatures, making it an ideal material for insulating sleeves.
4.Chemical Corrosion Resistance: Excellent resistance to most acids, alkalis, salts, and molten metals (except for hydrofluoric acid and high-temperature corrosion from strong alkalis).
5.High Mechanical Strength: High compressive and flexural strength, but is a brittle material with poor resistance to mechanical impact.
6.Low Coefficient of Thermal Expansion: Good dimensional stability and relatively good thermal shock resistance (but not as good as zirconium oxide).
7.Bio-Inert: High-purity alumina is harmless to human tissue.
Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Product Packaging
Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Qualified products are carefully packed in protective wooden boxes to ensure safe transportation and delivery.
Wear Resistance Insulating Alumina Ceramic Pipe Ceramic Structure Tube Custom Sizes
Frequently Asked Questions
Q1. Do you provide product samples?
Yes, we provide samples subject to availability. A nominal sample fee may apply in some cases, and shipping costs are borne by the customer.
Q2. What are your accepted payment methods?
We accept T/T (bank transfer) in advance, Western Union, Alipay, and PayPal.
Q3. What is your typical delivery lead time?
Lead times vary depending on product requirements, including material selection, dimensions, and specific manufacturing processes.
Q4. Do you perform quality inspection before shipment?
Yes, we conduct 100% inspection of all goods prior to delivery to ensure they meet specified standards.
Q5. What other ceramic materials do you offer?
We supply a range of advanced ceramic materials, including Alumina, Zirconia, Aluminum Nitride, Boron Nitride, Silicon Nitride, Machinable Glass Ceramic, and related specialized ceramics.
