L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
Specifications
Apply :
Router
Shell material :
ABS + Nickeled Plated
Contact Plating :
Gold Palting
Gender :
Female
Insulation Material :
PBT
Brand Name :
FUYCONN
Model Number :
FUYV.35018
Certification :
ISO
Place of Origin :
China
MOQ :
10pcs
Price :
USD0.2-USD2/pc
Packaging Details :
Vacuum Tray + Carton
Product name :
V.35 Connector
Contact material :
Phosphorous Bronze
Connector type :
Crimping
Number of Positions :
1 - 34 Pin
Description
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
Catalog: V.35 CONNECTOR.pdf
V.35 Male Crimping Connector Overview

V.35 series connectors have been designed for use in industrial and commercial telecommunication systems, providing a simple and inexpensive solution that allows for superior speed and noise immunity through differential signalling on data and clock lines.

Key Features
  • Widely used on DSU, CSU, router, and frame relay systems worldwide
  • Achieves speeds of up to 2 mbps
  • Can be loaded with 1 to 34 contacts per connector
  • Custom loading available in any configuration
Product Specifications
Product Type Features
Connector Classification V.35 (For CISCO ROUTER) Connector
Product Name V.35 PCB Right Angle Connector Type
Connector Model FUYV.35017
No. of Pins 1 - 34 pin
Contact Gender Plug
Type Crimping Type
Terminal and Shell
Insulator Material PBT & Glass-fibre Reinforced
Contact Coating 1U", 3U", 5U", 10U", 15U", 30U"
Terminal Material Phosphor Bronze
Shell All Plastic
Electrical Specifications
Current Rating 7 AMP
Dielectric Withstanding AC 1200V min (for 1 minute)
Insulation Resistance 1000 MΩ min (at 500V DC)
Contact Resistance 35 MΩ max (mated)
Working Temperature -55°C to +105°C
Technical Data
L Shape Plastic Housing 34 Pins Female Crimping V.35 Router Connector with Shield Shell
Packaging Information
  • Connector Body: Vacuum Tray
  • Terminal: 3000 pieces per reel
Applications
  • CISCO Router
  • Industrial telecommunication systems
  • Commercial Telecommunication
  • DSU, CSU
  • Frame relay systems
