48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
Specifications
Payment Terms :
T/T,Paypal
Brand Name :
FUYCONN
Model Number :
FUYDIN184-348S
Place of Origin :
China
MOQ :
10
Price :
USD0.6-USD2
Supply Ability :
100000000/month
Delivery Time :
1-4 weeks
Packaging Details :
Tray + Carton
Terminals Type :
Straight / Vertical
Pitch :
5.08mm
Number of Rows :
3 rows
Insulator Color & Material :
Grey & PBT
Gender :
Female
Product Line :
Power Connector
Contact Plating :
Gold plating(1u",3u",5u",10u",15u")
Number of Terminal :
3*16P 48pin
Connector Type :
PCB Type
Contact pin Material :
Phosphor Bronze
Product Category :
DIN41612 Connector
Description
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
Product Overview

PCB Straight 3 rows 48pin Eurocard 41612 Connector, Vertical PCB 3rows Female 3*16P 48P 5.08mm Power Type DIN41612 Connector

Product Catalog: DIN41612 CONNECTOR.pdf

DIN 41612 is a DIN standard for electrical connectors widely used in rack-based electrical systems. Standardization of these connectors is essential for open systems where components from different suppliers need to operate together. The most widely known application of DIN 41612 connectors is in the VME bus system.

The DIN 41612 standard has been widely accepted for various interconnection applications in telecommunications and data markets worldwide. DIN connectors with three rows (a, b, c) of contacts on 0.100" (2.54mm) square grid are available in wire-wrap or solder tail type terminations. Available pin configurations include 5pin, 10pin, 15pin, 20pin, 30pin, 32pin, 48pin, 64pin, and 96pin.

Product Specifications
Product Line: DIN41612 Connector
Product Name: Power DIN 41612 Connector
Connector Type: Power Connector
Connector Gender: Female
Number of Positions: 3*16 (48pin)
Number of Rows: 3 rows
Contact Material: Brass
Contact Plating: 1U", 3U", 5U", 10U", 15U", 30U"
Insulation Material: PBT
Color: Gray
Terminal Type: Straight
Pitch: 5.08mm
Electrical Specifications
Current Rating: 5.6Amp
Voltage Rating: DC 1000v per minute
Insulator Resistance: 1000MΩ MIN. (at 500V DC)
Operation Temperature: -55°C to +105°C
48Pin Power DIN41612 Connector PCB Straight Female 3*16pin 5.08mm Pitch
Application Information

Eurocard line connectors are available in board-to-board, wire-to-board, ribbon cable-to-board, and high-current configurations. Our Eurocard connectors incorporate internationally accepted design advantages of DIN 41612 and IEC 60603-2 two-piece connectors in a quality design that provides high Signal Integrity (SI) and electrical performance. With a broad portfolio, it's easy to find the right connector type and style for your application. Common Bus Systems include STE Bus, CIMBUS, FUTUREBUS, VMEBus, MULTIBUS (II), NUBUS, VXi Bus, and VME 64X.
