Desktop High Speed Refrigerated Centrifuge Machine 20000r/min Speed TGL-20MC
Desktop High Speed Refrigerated Centrifuge Machine 20000r/min Speed TGL-20MC
Specifications
Brand Name :
xiangrui
Model Number :
TGL-20MC
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
50 sets/month
Delivery Time :
5-8 work days
Packaging Details :
Wooden Case
Overall dimensions (LxWxH) :
600mmx570mmx370mm
Maximum speed :
20000r/min
Maximum relative centrifugal force :
27890xg
Maximum capacity :
4x100ml
Speed accuracy :
± 20r/min
Time setting range :
1min~999min
Temperature setting range :
-20～+40℃
Temperature control accuracy :
±1℃
Compressor unit :
Imported high-performance compressor unit, environmentally friendly refrigerant R134a
Overall machine noise :
<58dB(A)
Power supply :
AC220V 50Hz 18A
Net weight :
78kg
Description

TGL-20MC/22MC Desktop High Speed Refrigerated Centrifuge

Main technical performance
1. Microcomputer control, AC variable frequency motor drive, stable operation, low noise and high speed accuracy.
2. Touch panel, programmable operation, host operating parameters can be set according to needs and automatically stored.
3. TGL-20MC is a large-screen LCD display, TGL-20MC is a digital display, humanized interface, simple and convenient operation.
4. Real-time reading conversion and setting between rpm/RCF, convenient and fast.
5. Equipped with electronic door lock, equipped with various protection functions such as door cover self-locking, overspeed, overtemperature, etc.; automatic fault alarm function, safe and reliable.
6. It has 9 programs of increase/decrease rate curve, and the increase/decrease time can be set as needed.
​

Application areas
TGL-20MC desktop high-speed refrigerated centrifuge is widely used in the fields of clinical medicine, biochemistry, genetic engineering, and immunology. It is an essential instrument for centrifugal separation in comparative hospitals, scientific research units, and universities.

Adapt rotor parameters

Rotor number Rotor capacity Maximum speed Maximum relative centrifugal force Adapter available
No. 1 rotor 12x1.5/2.2ml 20000r/min 27890xg 0.2ml, 0.5ml
No. 2 horn rotor 24x1.5/2.2ml 13200r/min 16110xg 0.2ml, 0.5ml
No. 3 rotor 8/10x5ml 13000r/min 11400xg 0.5ml, 1.5ml
No. 4 horn rotor 12x10ml 12000r/min 14800xg 1.5ml, 5ml
No. 5 rotor 8x15ml 12000r/min 14800xg 10ml
No. 6 rotor 48x0.5ml 16000r/min 23699xg
No. 7 rotor 6x50ml 12000r/min 13000xg
No. 8 rotor 4x100ml 9800r/min 10600xg
