12/10D-G Strong Abrasion Resistance Sand Gravel Pump Good Cavitation Performance
12/10D-G Strong Abrasion Resistance Sand Gravel Pump Good Cavitation Performance
Specifications
Brand Name :
SHIZA
Model Number :
12/10D-G
Certification :
IOS
Place of Origin :
CHINA
MOQ :
1 set
Price :
based on quantity
Payment Terms :
T/T
Supply Ability :
200 sets monthy
Delivery Time :
15 work days
Packaging Details :
wooden case
Model :
12/10D-G
Capacity :
360-1440m³/h
Head :
10-60m
Speed :
400-850r/min
NPSH :
1.5-4.5m
Impeller.Dia. :
667mm
Description

12/10D-G Good Cavitation Performance Strong Abrasion Resistance Sand Gravel Pump

The 12/10D-G gravel pump is a centrifugal pump with a horizontal, single-shell pump construction. The gravel pump adopts a single pump shell structure connected by a cassette. It is a single-stage single-suction horizontal horizontal centrifugal pump, which has the advantages of light weight, good cavitation performance, strong anti-abrasive property, wide over-flow passage, convenient installation and use, etc. Continuous transport of large particles of strong abrasive.

The gravel pump is composed of a pump head, a sealing assembly, a bearing assembly, a bracket, etc., and the bearing lubrication method is grease lubrication. The over-current component impeller, pump body, front guard plate and rear guard plate are all made of strong anti-wear alloy cast iron or wear-resistant alloy steel.

According to the performance of the slurry pump, the speed of the slurry pump is increased by changing the size of the slurry pump motor wheel, and the lift is correspondingly improved, which can meet the requirements of the cyclone, and the working effect of the cyclone reaches the design requirements. G-type gravel pump-GH type high-lift gravel pump dredging pump, also known as gravel pump, the impeller flow path is spacious, the material is highly wear-resistant, widely used in pebble and large particles, especially the application of gravel pump, which requires large flow capacity of the environment .

Type Notation

12--Suction diameter(inch)

10--Discharge diameter(inch)

D--Sopport Type

G--Pump Model
