Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 5-12
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T
Supply Ability :
300sets 30days
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Application :
Industrial Exhaust Ventilation
Main shaft :
High-strength carbon structural steel
Motor type :
Three Phase AC Motor
Material :
Stainless Steel
Delivery time :
30 days
Color :
Customer's Requirement
Customized Support :
ODM OEM OBM
Mounting :
FREE STANDING
Warranty :
1 Year
keyword :
Blowers,Industrial Fan,High Efficiency Centrifugal Blower,Induced Draft Fan
Description
Product Description

The 4–22kW High-Quality Carbon Steel Sintering Blower & Induced Draft Fan features robust construction, high-temperature and wear resistance. Ideal for flue gas handling and dust extraction in sintering processes. Reliable performance and customizable for demanding industrial applications like metallurgy.

4-22kW Industrial Centrifugal Blower for Sintering Processes
Specification
Series no.
5-12series
Feature selection
Normal
anti-corrosion
wear-resisting
High temperature
anti-explosion
Remarks
Performance
Impeller diameter
400-3300mm
Rotation speed
≤4000rpm
Pressure range
684-8687Pa
Flow range
590-700735m³/h
Structure
Blade type
Backward, Straight, Aerofoil type
Impeller support
SWSI(Single Width, Single Inlet), DWDI(Double Width, Double Inlet), Overhung type
Lubrication method
Oil bath lubrication, grease lubrication, lubrication oil station
Can be specified
Cooling method
Air cooling, Water cooling, Oil cooling
Can be specified
Driven mode
Direct driven, Coupling driven, Belt driven
Can be specified
Gas composition
Gas temperature
Normal
Customer request
Customer request
≥250℃
Customer request
gascharacteristic
Clean gas
Corrosive gas
Particulate dust
High temperature gas
Flammable gas, explosive gas
System configuration
Motor brand
Chinese famous brand, ABB, Siemens, WEG etc
Can be specified
Impeller
High quality carbon steel
FRP, Stainless steel, Rubber Lining
Wear-resistant layer or wear-resistant liner, ceramic patch
High temperature high quality alloy steel
FRP, Aluminum alloy
Can be specified
Air inlet cone
High quality carbon steel
FRP, Stainless steel, Rubber Lining
High quality carbon steel
High quality carbon steel
High quality carbon steel
Can be specified
Casing
High quality carbon steel
FRP, Stainless steel, Rubber Lining
High quality carbon steel
High quality carbon steel
High quality carbon steel
Can be specified
Air damper
High quality carbon steel
FRP, Stainless steel, Rubber Lining
High quality carbon steel
High quality carbon steel
High quality carbon steel
Can be specified
Main shaft
High strength carbon steel, Alloy structural steel
Can be specified
Bearing
ZWZ, SKF, FAG, NSK
Can be specified
4-22kW Industrial Centrifugal Blower for Sintering Processes
Product features :
1. It is capable of outputting a higher outlet pressure while providing more gas flow with lower noise. Stable operation at higher media temperatures.
2. The fan speed can be flexibly set by matching different pulley diameters to make the fan run at the highest efficiency point and reduce energy waste.
3. Motor sliding guides are provided for easy tensioning of the belt to reduce energy loss due to belt slack.
4. The bearing housing is reserved for temperature and vibration sensor mounting positions, for convenient to install the fan operation monitoring device.
5. Use liquid lubricant, it is not necessary to open the bearing housing to replace and fill the oil. The bearing housing is provided with an observation window for easy observation of the quality and stock of the lubricating oil.
6. The bearing housing uses a labyrinth mechanical seal, a unique Leak proof oil design inside, a vent hole at the top, and a sealant on the joint, completely eliminating the possibility of oil leakage in the bearing housing.
7. The impeller is annealed to completely eliminate the internal stress generated during welding, ensuring that the impeller does not undergo creep and cracks.
8. The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.
9. After the production is completed, all products are tested for running and vibration values for reliable operation.
Please provide the fan operating conditions and parameter information, and the business manager will give you a quote
