Dry quenching circulating fan for metallurgical industry
Dry quenching circulating fan for metallurgical industry
Specifications
Brand Name :
SIMO BLOWER
Model Number :
5-10
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
$500-1000
Payment Terms :
L/C, T/T, D/P
Supply Ability :
300sets 30days
Delivery Time :
35days(To be negotiated)
Packaging Details :
1.export wooden case packing 2.bare package with steel pallet 3.other export package
Product Name :
Dry quenching circulating fan
Application :
Cooling and heat recovery,Dry quenching coke circulating gas conveying
Material :
High-quality carbon steel/304/316, customizable
Air volume :
270000~450000m³/h
Pressure boost :
11000~12100Pa
operating temperature :
150~170℃
Voltage :
380V/415V/440V/660V/6KV/10KV
Size :
Customized
Power source :
Three Phase AC Motor
Bearing :
SKF/FAG/By your demand
Warranty :
1 Year
Description
Dry Quenching Circulating Fan for Metallurgical Industry
As the core power equipment of the Coke Dry Quenching (CDQ) plant, the circulating fan performs the critical task of driving the inert circulating gas (primarily nitrogen and carbon dioxide) within the closed-loop system to cool red-hot coke and recover its sensible heat. Operating under severe conditions, it must continuously withstand high temperatures (≤250°C), high dust concentrations (coke fines), and potentially corrosive gas components (e.g., trace H₂S, SO₂) over extended periods. Its performance directly determines the coke quenching efficiency, steam generation rate, and the overall safety and stability of the system.
Dry quenching circulating fan for metallurgical industry
Features
Dry quenching circulating fan for metallurgical industry
  • Rearward-curved blades for high efficiency and energy savings
  • Resistant to dust accumulation and wear
  • Corrosion-resistant construction
  • Leak-free operation
  • Reasonable split design for casing and air inlet facilitates maintenance
Product Parameter Information
Typical Performance Parameters Conveyed Medium Structural Type
Air volume: 270,000~450,000 m³/h
Pressure rise: 11,000~12,100 Pa
Operating temperature: 150~170℃		 Dry quenching circulating gas Double-support centrifugal type
Manufacturing Process
Dry quenching circulating fan for metallurgical industry
Application
Dry quenching circulating fan for metallurgical industry
Company Profile
Dry quenching circulating fan for metallurgical industry Dry quenching circulating fan for metallurgical industry
Related Cases
Dry quenching circulating fan for metallurgical industry
FAQ
Dry quenching circulating fan for metallurgical industry
