Dust removal fan for converters in the metallurgical industry
Dust removal fan for converters in the metallurgical industry
Specifications
Brand Name :
SIMO BLOWER
Model Number :
7-08
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
$500-1000
Payment Terms :
L/C, T/T, D/P
Supply Ability :
300sets 30days
Delivery Time :
35days(To be negotiated)
Packaging Details :
1.export wooden case packing 2.bare package with steel pallet 3.other export package
Product Name :
Dust removal fan
Application :
Dust removal fan for converters
Material :
High-quality carbon steel/304/316, customizable
Air volume :
2000~4000m³/min
Pressure boost :
28500Pa
operating temperature :
65℃
Voltage :
380V/415V/440V/660V/6KV/10KV
Size :
Customized
Power source :
Three Phase AC Motor
Bearing :
SKF/FAG/By your demand
Warranty :
1 Year
Description
Dust Removal Fan for Converters in the Metallurgical Industry
Specifically designed for the capture and purification systems of primary converter gas and secondary fugitive dust, this fan is the core power equipment for ensuring ultra-low emissions and clean production in steelmaking plants. It must handle severe, shock-type load fluctuations within extremely short periods, caused by cyclical processes such as hot metal charging, blowing, and tapping. Its performance directly impacts the dust collection system's efficiency, stack visual appearance, and overall plant environmental compliance.
Dust removal fan for converters in the metallurgical industry
Features
Dust removal fan for converters in the metallurgical industry
Backward-curved blades, high efficiency and energy saving, blades with wear-resistant overlay or wear-resistant lining, wear-resistant plate lining inside the casing, allowing the rotor to be lifted out for maintenance without moving the fan inlet and outlet connections.
Product Parameter Information
Product Name Typical Performance Parameters Conveyed Medium Structural Type
Wet primary dust collector fan Air volume: 2000~4000m³/min
Pressure boost: 28500 Pa
Operating temperature: 65℃		 Converter gas Double-supported centrifugal type
Dry primary dust collector fan Air volume: 2500m³/min
Pressure boost: 7300 Pa
Operating temperature: 160℃ (Maximum 200℃)		 Converter gas Double-support axial flow
Manufacturing Process
Dust removal fan for converters in the metallurgical industry
Application
Dust removal fan for converters in the metallurgical industry
