Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 4-10
Certification :
CE, ISO
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
30-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
After-sales Service Provided :
Engineers available to service machinery overseas
Application :
Building ventilation, mine ventilation, smoke extraction, drying, clinker cooling, gas conveying, lightweight material conveying, industrial boiler systems
Blades :
Backward curve blade
Blade Number :
12
Characteristics :
Low pressure
Transmission method :
A (Direct motor drive), C (Belt pulley drive), D (Coupling drive), F (Intake box type coupling drive)
Impeller Testing :
Dynamic blancing adjusting
Cooling Type :
Air cooling/Circulating Water cooling
Description
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan
Product Overview

Our single-suction cantilever support belt-driven centrifugal fan is engineered for reliable performance in industrial ventilation, exhaust, and process air applications. The cantilever support design positions the impeller overhung on the shaft, providing simplified maintenance access and reduced footprint.

The belt-drive configuration allows flexible speed adjustment to precisely match system requirements while reducing motor starting torque. Constructed from durable materials with welded steel housing, this fan delivers long-term reliability in continuous-duty environments.

Key Features
  • Precision-engineered impellers with aerodynamically optimized blades for efficient airflow
  • Dynamically balanced rotating assemblies for smooth, low-vibration operation
  • Heavy-duty bearing systems with easy lubrication access
  • Robust cantilever support structure ensures stable performance under varying loads
  • Available in multiple sizes with customizable options
  • Various material grades including carbon steel and stainless steel
  • Customizable inlet/outlet configurations and accessory packages
Product Structure
Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction Customized Single-Suction Cantilever Support Belt-Driven Centrifugal Fan with Adjustable Speed and Durable Construction
Technical Specifications
Series Model Rotation Speed (r/min) Total Pressure (Pa) Air Capacity (m³/h) Power (kW)
4-108C14502104-140016156-3099318.55
9C960-1450775-266815229-4412811-37
10C730-1450553-330115886-605337.5-55
11C730-1450669-400321144-8057011-90
12C730-1450797-477725661-10460015-132
14C730-14501086-654143591-16610037-315
16C580-960895-370951699-16415045-185
18C580-9601133-471073610-23373075-280
20C580-9601400-5837100970-320610110-520
22C480-9601216-6865116000-434000140-850
25C480-7301579-5138171000-484000165-700
28C375-7301205-6400187000-680000320-1250
29.5C596-7453236-7218348000-810000800-1600
Our Advantages
